BLACK & WHITE VIDEO CAMERAS
Supplied Accessories
Lens connector (1)
Lens mount cap (1)
Operation manual (1)
Optional Accessories
Camera adaptor YS-W150P, YS-W250P
Manual iris lens VCL-S03XM (3.6 mm, F1.6)
VCL-S06XM (6.0 mm, F1.2)
VCL-S12XM (12 mm, F1.2)
Auto iris lens VCL-S03XEA (3.6 mm, F1.6)
VCL-S06XEA (6.0 mm, F1.2)
VCL-S12XEA (12 mm, F1.2)
CCD B/W Video Camera
SSC-M370CE
•Especially designed for surveillance applications
•
High density 1/2-inch IT Hyper HAD CCD offers extremely
high resolution of 570 TV lines and high sensitivity with
a minimum illumination of 0.3 lx at F1.2 (50 IRE)
•Excellent signal-to-noise ratio of 50 dB
•CCD IRIS function allows use of inexpensive manual iris
lenses
•Variable speed electronic shutter
Shutter speeds — 1/50, 1/120, 1/250, 1/500, 1/1000,
1/2000, 1/4000, 1/10000 (seconds)
•Accepts C-mount lenses
•External synchronization with VS
•Single cable operation (video/sync/power triple
multiplex transmission) for easy installation with the
optional YS-W150P/W250P Camera Adaptor (Mode A)
•Monitor out function for on-the-spot camera positioning
(Mode A)
•12 V DC power supply can also be used (Mode B)
Rear Panel
Lens shown is an option
