COLOUR VIDEO PRINTERS
Colour Video Printer
UP-2850P/2800P
•UP-2850P: four frame memories,
UP-2800P: one frame memory
•
High quality pictures: high resolution of 310 dpi,
860 (H) x 976 (V) dots in normal mode
•8 bit/256 gradations in yellow, magenta and cyan
•Near A6 size print (130 x 88 mm/5
1
/8 x 3
1
/2 inches) in
approx. 35 seconds
•Easy-to-use operation menu displayed on the built-in
LCD or the connected monitor
•Wireless or wired remote control operations
•Multiple video inputs of RGB, Y/C and composite
CCIR/PAL video signals
•Versatile print modes
Supplied Accessories
Colour printing pack (for 10 prints) (1)
Paper tray (1)
Paper cover (1)
AC power cable (1)
Operation manual (1)
Specifications
UP-2850P/2800P
Printing method: Dye transfer sublimation thermal printing
Thermal head: 1024 elements (12.2 dots/mm)
Printing paper size: 130 x 88 mm (5
1
/8 x 3
1
/2 inches)
Picture size: Max. 110 x 80 mm (4
3
/8 x 3
1
/4 inches)
Picture elements: Max. 860 (H) x 976 (V) dots
Gradations: 256 levels process (Yellow, Magenta, Cyan)
over 16 million colours per dot
Picture memory: UP-2850P: Four frame memories
UP-2800P: One frame memory
Printing time: Approx. 35 seconds
Input terminals:
RGB analogue (BNC x 4, R,G,B, Sync)
RGB: 0.7 Vp-p, 75 Ω, unbalanced
Sync: 0.2 to 4.0 Vp-p, negative, 75 Ω, unbalanced
Y/C separate (4-pin S terminal)
Y: 1.0 Vp-p, sync negative, 75 Ω, unbalanced
C: 0.3 Vp-p, 75 Ω, unbalanced
Composite video (BNC)
CCIR/PAL:1.0 Vp-p, sync negative, 75 Ω, unbalanced
Output terminals: RGB analogue (BNC x 4, R, G, B, Sync)
RGB: 0.7 Vp-p, 75 Ω, unbalanced
Sync: 1.0 Vp-p, negative, 75 Ω, unbalanced
Y/C separate (4-pin S terminal)
Y: 1.0 Vp-p, sync negative, 75 Ω, unbalanced
C: 0.3 Vp-p, 75 Ω, unbalanced
Composite video (BNC)
CCIR/PAL:1.0 Vp-p, sync negative, 75 Ω, unbalanced
Control terminals:
Control (for the optional foot switch FS-36/20 and
remote control unit RM-91): stereo mini jack
Control (for the supplied remote control unit):
special mini jack
RS-232C interface port (D-sub 25-pin)
Power requirements: AC 220 to 240 V, 50/60 Hz
Power consumption: Max. 1.0 A
Mass: Approx. 10.5 kg (23 lb 2 oz)
Dimensions:
Unit: mm (inches)
Optional Accessories
Wired/Wireless Remote Commander RM-5500
Remote Control Unit RM-91
Foot Switch FS-36
Foot Switch FS-20
Colour Printing Pack UPC-2010 (for 200 prints)
Black and White Printing Pack UPC-2020 (for 200 prints)
Colour Postcard Printing Pack UPC-2070E (for 150 prints)
Self-adhesive Colour Printing Pack UPC-20S01 (for 200 prints)
16-split Self-adhesive Pre-cut Color Printing Pack
UPC-20S16 (for 200 prints)
4-split Self-adhesive Pre-cut Color Printing Pack
UPC-20S04 (for 200 prints)
Paper Ejector UPA-2001
Paper Tray for UPC-2070E: UPA-2002
R.G.B.
