Sony CCTV Systems - Rear Panel

41
MULTIPLEXERS
YS-DX316P/DX216CE Typical System
Video Camera 1
Time Lapse VCR
(ex. SVT-L230P)
Video Camera 16
Colour Video Monitor
(ex. SSM-20N5E)
SW OUT
ALARM
IN
VIDEO IN
VIDEO OUT
MON OUT 1
ALARM OUT
PB IN
REC
OUT
VIDEO OUT
(coaxial cable)
YS-DX316P/DX216CE
VIDEO INPUT
1to16
VIDEO OUT
(coaxial cable)
Colour Video Monitor
(ex. SSM-20N5E)
MON OUT 2
YS-DX316P
YS-DX216CE
Rear Panel
