COLOUR VIDEO PRINTERS
Colour Video Printer
UP-2300P/2100P
•One frame memory capability
•
UP-2300P: 310 dpi resolution
UP-2100P: 182 dpi resolution
•8 bit/256 gradations in yellow, magenta and cyan
•Near A6 size print (130 x 88/5
1
/8 x 3
1
/2 inches) in
approx. 35 seconds (UP-2300P) or 60 seconds
(UP-2100P)
•Easy-to-use operation menu displayed on the monitor
•Wireless or wired remote control operations
•Multiple video inputs of Y/C and composite CCIR/PAL
video signals
•Versatile print modes
UP-2300P Rear Panel
Supplied Accessories
Colour printing pack (for 10 prints) (1)
Paper tray (1)
Paper cover (1)
AC power cable (1)
Operation manual (1)
Specifications
UP-2300P/2100P
Printing method: Dye transfer sublimation thermal printing
Thermal head: UP-2300P: 1024 elements (12.2 dots/mm)
UP-2100P: 608 elements (7.2 dots/mm)
Printing paper size: 130 x 88 mm (5
1
/8 x 3
1
/2 inches)
Picture size: 110 x 80 mm (4
3
/8 x 3
1
/4 inches)
Picture elements: UP-2300P: 860 (H) X 976 (V) dots
UP-2100P: 720 (H) X 564 (V) dots
Gradations: 256 levels process (Yellow, Magenta, Cyan)
over 16 million colours per dot
Picture memory: One frame memory
Printing time: UP-2300P: 35 seconds
UP-2100P: 60 seconds
Input terminals:
Y/C separate (4-pin S terminal)
Y: 1.0 Vp-p, sync negative, 75 Ω, unbalanced
C: 0.3 Vp-p, 75 Ω, unbalanced
Composite video (BNC), Phono
CCIR/PAL:1.0 Vp-p, sync negative, 75 Ω, unbalanced
Output terminals:
Y/C separate (4-pin S terminal)
Y: 1.0 Vp-p, sync negative, 75 Ω, unbalanced
C: 0.3 Vp-p, 75 Ω, unbalanced
Composite video (BNC)
CCIR/PAL:1.0 Vp-p, sync negative, 75 Ω, unbalanced
Control terminals: Control (for the optional foot switch FS-36/20):
stereo mini jack
Control (for the supplied remote control unit):
special mini jack
RS-232C interface port (D-sub 25-pin)*
Power requirements: AC 220 to 240 V, 50/60 Hz
Power consumption: Max. 1.0 A
Mass: UP-2300P: 10 kg (22 lb 1 oz)
UP-2100P: 9 kg (19 lb 13 oz)
Dimensions:
Unit: mm (inches)
Optional Accessories
Wired/Wireless Remote Commander RM-5500
Remote Control Unit RM-91
Foot Switch FS-36
Foot Switch FS-20
Colour Printing Pack UPC-2010 (for 200 prints)
Black and White Printing Pack UPC-2020* (for 200 prints)
Colour Postcard Printing Pack UPC-2070E* (for 150 prints)
Self-adhesive Colour Printing Pack UPC-20S01 (for 200 prints)
16-split Self-adhesive Pre-cut Color Printing Pack
UPC-20S16* (for 200 prints)
4-split Self-adhesive Pre-cut Color Printing Pack
UPC-20S04* (for 200 prints)
Paper Ejector UPA-2001*
Paper Tray for UPC-2070E: UPA-2002*
* UP-2300P ONLY
UP-2100P Rear Panel
