– 46 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY HP
R158 1-216-111-00 METAL CHIP 390K 5% 1/10W
R159 1-216-101-00 METAL CHIP 150K 5% 1/10W
R161 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
**************************************************************
* A-4699-620-A DISPLAY BOARD, COMPLETE
************************
* 3-362-478-01 HOLDER (T), LED
* 4-989-724-01 HOLDER (FL)
< CAPACITOR >
C801 1-162-210-31 CERAMIC 30PF 5% 50V
C802 1-164-159-11 CERAMIC 0.1uF 50V
C810 1-161-494-00 CERAMIC 0.022uF 25V
C811 1-162-282-31 CERAMIC 100PF 10% 50V
C812 1-162-282-31 CERAMIC 100PF 10% 50V
C813 1-164-159-11 CERAMIC 0.1uF 50V
C814 1-161-494-00 CERAMIC 0.022uF 25V
C851 1-126-968-11 ELECT 100uF 20% 6.3V
< CONNECTOR >
* CN810 1-568-836-11 SOCKET, CONNECTOR 17P
< DIODE >
D802 8-719-303-00 DIODE SEL2510C-C
D803 8-719-301-52 DIODE SEL2810A-C
D804 8-719-301-44 DIODE SEL2410E-D
D805 8-719-301-44 DIODE SEL2410E-D
D810 8-719-057-97 DIODE SEL5923A-TP15
< FLUORESCENT INDICATOR >
FL810 1-517-664-11 INDICATOR TUBE, FLUORESCENT
< COMPOSITION CIRCUIT BLOCK >
IB801 1-232-362-11 COMPOSITION CIRCUIT BLOCK
< IC >
IC810 8-749-014-66 IC NJL56H400
IC811 8-759-337-52 IC LC75721E
< TRANSISTOR >
Q801 8-729-029-66 TRANSISTOR DTC114ESA
Q802 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R801 1-249-429-11 CARBON 10K 5% 1/4W
R802 1-247-807-31 CARBON 100 5% 1/4W
R803 1-249-408-11 CARBON 180 5% 1/4W F
R804 1-247-807-31 CARBON 100 5% 1/4W
R805 1-247-807-31 CARBON 100 5% 1/4W
R806 1-249-441-11 CARBON 100K 5% 1/4W
R807 1-249-441-11 CARBON 100K 5% 1/4W
R808 1-249-441-11 CARBON 100K 5% 1/4W
R811 1-249-415-11 CARBON 680 5% 1/4W F
R812 1-249-417-11 CARBON 1K 5% 1/4W F
R813 1-249-419-11 CARBON 1.5K 5% 1/4W F
R814 1-249-421-11 CARBON 2.2K 5% 1/4W F
R815 1-247-843-11 CARBON 3.3K 5% 1/4W
R816 1-249-427-11 CARBON 6.8K 5% 1/4W F
R817 1-249-415-11 CARBON 680 5% 1/4W F
R818 1-249-417-11 CARBON 1K 5% 1/4W F
R819 1-249-419-11 CARBON 1.5K 5% 1/4W F
R820 1-249-421-11 CARBON 2.2K 5% 1/4W F
R821 1-247-843-11 CARBON 3.3K 5% 1/4W
R822 1-249-427-11 CARBON 6.8K 5% 1/4W F
R823 1-249-431-11 CARBON 15K 5% 1/4W
R824 1-249-431-11 CARBON 15K 5% 1/4W
R830 1-247-807-31 CARBON 100 5% 1/4W
R831 1-249-441-11 CARBON 100K 5% 1/4W
R832 1-249-441-11 CARBON 100K 5% 1/4W
R833 1-247-807-31 CARBON 100 5% 1/4W
R834 1-247-807-31 CARBON 100 5% 1/4W
R835 1-247-807-31 CARBON 100 5% 1/4W
R851 1-247-807-31 CARBON 100 5% 1/4W
R852 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S801 1-554-303-21 SWITCH, TACTILE (X-FADE)
S802 1-554-303-21 SWITCH, TACTILE (NO DELAY)
S803 1-554-303-21 SWITCH, TACTILE (CLEAR)
S804 1-554-303-21 SWITCH, TACTILE (CHECK)
S805 1-554-303-21 SWITCH, TACTILE ())
S806 1-554-303-21 SWITCH, TACTILE (0)
S807 1-554-303-21 SWITCH, TACTILE (MEGA CONTROL)
S808 1-554-303-21 SWITCH, TACTILE (§ OPEN/CLOSE)
S809 1-554-303-21 SWITCH, TACTILE (DISC SKIP)
S810 1-554-303-21 SWITCH, TACTILE (EX-CHANGE)
S811 1-554-303-21 SWITCH, TACTILE (p)
S812 1-554-303-21 SWITCH, TACTILE (P)
S813 1-554-303-21 SWITCH, TACTILE (·)
S814 1-475-543-11 ENCODER, ROTARY
(= AMS + PUSH ENTER)
**************************************************************
* 1-665-359-11 HP BOARD
********
< CAPACITOR >
C771 1-162-294-31 CERAMIC 0.001uF 10% 50V
C772 1-162-294-31 CERAMIC 0.001uF 10% 50V
C773 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN771 1-568-941-11 PIN, CONNECTOR 3P
< JACK >
J771 1-568-519-41 JACK, LARGE TYPE (PHONES)
BD
