Sony CDP-CE525 Service Manual

– 47 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
< RESISTOR >
R771 1-249-401-11 CARBON 47 5% 1/4W F
R772 1-249-401-11 CARBON 47 5% 1/4W F
**************************************************************
* 1-665-358-11 KEY BOARD
*********
< CONNECTOR >
* CN701 1-568-852-11 SOCKET, CONNECTOR 9P
CN702 1-750-195-11 CONNECTOR, BOARD TO BOARD 6P
< RESISTOR >
R711 1-249-415-11 CARBON 680 5% 1/4W F
R712 1-249-417-11 CARBON 1K 5% 1/4W F
R713 1-249-415-11 CARBON 680 5% 1/4W F
R714 1-249-419-11 CARBON 1.5K 5% 1/4W F
< SWITCH >
S711 1-554-303-21 SWITCH, TACTILE (PEAK SEARCH)
S712 1-554-303-21 SWITCH, TACTILE (EDIT/TIME FADE)
S713 1-554-303-21 SWITCH, TACTILE (TIME/TEXT)
S714 1-554-303-21 SWITCH, TACTILE (FADER)
S715 1-554-303-21 SWITCH, TACTILE (INPUT)
**************************************************************
* 1-659-738-11 LOADING BOARD
*************
< MOTOR >
M802 A-4660-914-A MOTOR ASSY, LOADING (LOADING)
**************************************************************
* A-4724-016-A MAIN BOARD, COMPLETE (US,CND)
********************
* A-4724-017-A MAIN BOARD, COMPLETE (AEP,AUS)
********************
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
C301 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C302 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C303 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C305 1-124-443-00 ELECT 100uF 20% 10V
C306 1-124-442-00 ELECT 330uF 20% 6.3V
C307 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C311 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C317 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C321 1-110-489-11 CAPACITOR 1F 5.5V
C322 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C372 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C373 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C374 1-124-443-00 ELECT 100uF 20% 10V
C381 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C401 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C402 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C403 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C404 1-106-359-00 MYLAR 4700PF 5% 200V
C405 1-130-472-00 MYLAR 0.0012uF 5% 50V
C406 1-124-443-00 ELECT 100uF 20% 10V
C407 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C408 1-124-584-00 ELECT 100uF 20% 10V
C410 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C411 1-104-665-11 ELECT 100uF 20% 16V
C412 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C451 1-124-907-11 ELECT 10uF 20% 50V
C501 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C502 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C503 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C504 1-106-359-00 MYLAR 4700PF 5% 200V
C505 1-130-472-00 MYLAR 0.0012uF 5% 50V
C506 1-124-443-00 ELECT 100uF 20% 10V
C507 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C508 1-124-584-00 ELECT 100uF 20% 10V
C509 1-126-962-11 ELECT 3.3uF 20% 50V
C510 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C511 1-104-665-11 ELECT 100uF 20% 16V
C512 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C551 1-124-907-11 ELECT 10uF 20% 50V
C602 1-126-944-11 ELECT 3300uF 20% 16V
C603 1-126-942-61 ELECT 1000uF 20% 16V
C604 1-126-963-11 ELECT 4.7uF 20% 50V
C605 1-126-963-11 ELECT 4.7uF 20% 50V
C606 1-126-963-11 ELECT 4.7uF 20% 50V
C607 1-126-941-11 ELECT 470uF 20% 6.3V
C608 1-104-666-11 ELECT 220uF 20% 10V
C609 1-124-918-11 ELECT 47uF 20% 63V
C610 1-124-907-11 ELECT 10uF 20% 50V
C614 1-104-665-11 ELECT 100uF 20% 16V
C616 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C619 1-104-664-11 ELECT 47uF 20% 16V
C620 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C622 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C624 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C625 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C626 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C628 1-104-664-11 ELECT 47uF 20% 16V
C651 1-104-664-11 ELECT 47uF 20% 16V
< CONNECTOR >
CN401 1-750-640-11 CONNECTOR, FFC/FPC 23P
CN402 1-568-860-11 SOCKET, CONNECTOR 17P
* CN403 1-568-852-11 SOCKET, CONNECTOR 9P
* CN404 1-568-825-11 SOCKET, CONNECTOR 6P
* CN601 1-573-047-11 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D302 8-719-016-74 DIODE 1SS352
D321 8-719-016-74 DIODE 1SS352
D381 8-719-016-74 DIODE 1SS352
D601 8-719-210-33 DIODE EC10DS2
D602 8-719-210-33 DIODE EC10DS2
HP KEY LOADING
