Sony CDP-XA30ES - Wave Forms

– 33 –
• Wave forms
– MAIN BOARD –
5 IC101 $¶ (BCLK)
6.24 Vp-p
2.1186 MHz
– BD BOARD –
2 IC351 #™ (XOUT)
3 IC101 %£ (XPLCK)
4 IC101 %∞ (RFCK)
5.84 Vp-p
7.353 kHz
6 IC101 $∞ (LRCK)
6.32 Vp-p
44.053 kHz
5.92 Vp-p
4.00 MHz
7 IC101 #§ (RFAC)
200 mV/DIV, 500 nS/DIV
8 IC101 @ª (FE)
9 IC101 @¶ (TE)
!º IC101 (§ (MDP)
3.6Vp-p
131.58 kHz
0.1 Vp-p
8.4 Vp-p
1 IC302 !º (XIN)
2.02 Vp-p
45.455 MHz
6.8 Vp-p
4.310 MHz
1.25 Vp-p
+0.25
–0.20
