– 69 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R634 1-249-441-11 CARBON 100K 5% 1/4W
R635 1-247-890-11 CARBON 300K 5% 1/4W
R636 1-249-402-11 CARBON 56 5% 1/4W
R637 1-249-425-11 CARBON 4.7K 5% 1/4W
< VARIABLE RESISTOR >
VR405 1-223-747-11 RES, VAR, CARBON 10K/10K
(LINE OUT PHONE LEVEL)
************************************************************
* 1-663-579-11 LOADING MOTOR BOARD
*********************
< CAPACITOR >
C181 1-126-023-11 ELECT 100uF 20% 25V
C182 1-126-023-11 ELECT 100uF 20% 25V
C183 1-164-699-11 CERAMIC CHIP 0.0033uF 5% 50V
C184 1-126-059-11 ELECT 10uF 20% 50V
C185 1-163-038-00 CERAMIC CHIP 0.1uF 25V
< IC >
IC181 8-759-202-01 IC TA7256P
IC182 8-759-100-96 IC uPC4558G2
< RESISTOR >
R001 1-216-073-00 METAL CHIP 10K 5% 1/10W
R002 1-216-073-00 METAL CHIP 10K 5% 1/10W
R003 1-216-073-00 METAL CHIP 10K 5% 1/10W
R004 1-216-073-00 METAL CHIP 10K 5% 1/10W
R005 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R006 1-216-047-00 METAL GLAZE 820 5% 1/10W
R007 1-216-025-00 METAL GLAZE 100 5% 1/10W
R008 1-216-045-00 METAL CHIP 680 5% 1/10W
¡ R009 1-249-474-11 CARBON 1 5% 1/2W F
R010 1-216-001-00 METAL CHIP 10 5% 1/10W
************************************************************
* 1-663-581-11 LOADING SW BOARD
*****************
< SWITCH >
S152 1-762-424-11 SWITCH, MICRO (LOADING SW)
************************************************************
* A-4699-567-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C259 1-161-494-00 CERAMIC 0.022uF 25V
C260 1-162-215-31 CERAMIC 47PF 5% 50V
C261 1-136-850-11 FILM 0.1uF 5% 63V
C262 1-136-850-11 FILM 0.1uF 5% 63V
C263 1-136-850-11 FILM 0.1uF 5% 63V
C264 1-136-850-11 FILM 0.1uF 5% 63V
C266 1-136-850-11 FILM 0.1uF 5% 63V
C271 1-124-994-11 ELECT 100uF 20% 10V
C272 1-164-159-11 CERAMIC 0.1uF 50V
C274 1-164-159-11 CERAMIC 0.1uF 50V
C301 1-164-159-11 CERAMIC 0.1uF 50V
C306 1-162-208-31 CERAMIC 24PF 5% 50V
C307 1-164-159-11 CERAMIC 0.1uF 50V
C310 1-164-159-11 CERAMIC 0.1uF 50V
C320 1-128-200-11 ELECT 47uF 20% 63V
C321 1-128-202-11 ELECT 220uF 20% 63V
C322 1-117-775-11 FILM 0.1uF 10% 250V
C323 1-102-947-00 CERAMIC 10PF 5% 50V
C324 1-102-947-00 CERAMIC 10PF 5% 50V
C358 1-164-159-11 CERAMIC 0.1uF 50V
C359 1-126-012-11 ELECT 470uF 20% 16V
C360 1-124-686-71 ELECT 220uF 20% 16V
C362 1-117-914-51 ELECT 330uF 20% 25V
C363 1-117-914-51 ELECT 330uF 20% 25V
C364 1-124-686-71 ELECT 220uF 20% 16V
C370 1-164-159-11 CERAMIC 0.1uF 50V
C371 1-164-159-11 CERAMIC 0.1uF 50V
C501 1-136-850-11 FILM 0.1uF 5% 63V
C502 1-126-023-11 ELECT 100uF 20% 25V
C503 1-136-850-11 FILM 0.1uF 5% 63V
C504 1-128-198-11 ELECT 22uF 20% 50V
C505 1-136-850-11 FILM 0.1uF 5% 63V
C510 1-128-200-11 ELECT 47uF 20% 63V
C512 1-130-892-00 FILM 0.015uF 5% 63V
C516 1-136-850-11 FILM 0.1uF 5% 63V
C517 1-136-850-11 FILM 0.1uF 5% 63V
C518 1-128-200-11 ELECT 47uF 20% 63V
C519 1-128-198-51 ELECT 22uF 20% 63V
C520 1-128-200-11 ELECT 47uF 20% 63V
C521 1-130-973-00 FILM 0.022uF 5% 100V
C522 1-130-955-00 FILM 0.01uF 5% 100V
C523 1-130-955-00 FILM 0.01uF 5% 100V
C524 1-130-339-11 FILM 0.0056uF 5% 100V
C525 1-130-339-11 FILM 0.0056uF 5% 100V
C526 1-136-814-11 FILM 0.001uF 5% 100V
C527 1-136-814-11 FILM 0.001uF 5% 100V
C530 1-136-817-11 FILM 0.0033uF 2% 100V
C531 1-136-813-11 FILM 680PF 5% 100V
C532 1-128-201-11 ELECT 100uF 20% 50V
C533 1-137-506-11 FILM 0.47uF 10% 63V
C535 1-136-802-11 FILM 0.015uF 5% 100V
C536 1-128-198-51 ELECT 22uF 20% 63V
C537 1-128-201-11 ELECT 100uF 20% 50V
C601 1-136-850-11 FILM 0.1uF 5% 63V
C602 1-126-023-11 ELECT 100uF 20% 25V
C603 1-136-850-11 FILM 0.1uF 5% 63V
C604 1-128-198-11 ELECT 22uF 20% 50V
C605 1-136-850-11 FILM 0.1uF 5% 63V
C610 1-128-200-11 ELECT 47uF 20% 63V
MAINLOADING SWLOADING MOTORHP
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
