Sony CDP-XA30ES - Panel Parts List

– 71 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R501 1-259-380-11 CARBON 10 5% 1/6W
R502 1-259-380-11 CARBON 10 5% 1/6W
R503 1-259-380-11 CARBON 10 5% 1/6W
R504 1-259-380-11 CARBON 10 5% 1/6W
R505 1-249-455-11 CARBON 4.7 5% 1/4W
R506 1-249-520-11 CARBON 47 5% 1/4W
R508 1-249-911-11 CARBON 330 1% 1/4W
R509 1-249-911-11 CARBON 330 1% 1/4W
R510 1-249-887-11 CARBON 33 1% 1/4W
R511 1-249-887-11 CARBON 33 1% 1/4W
R512 1-249-931-11 CARBON 2.2K 1% 1/4W
R513 1-249-931-11 CARBON 2.2K 1% 1/4W
R514 1-249-933-11 CARBON 2.7K 1% 1/4W
R515 1-249-933-11 CARBON 2.7K 1% 1/4W
R516 1-249-553-11 CARBON 1.1K 5% 1/4W
R517 1-249-560-00 CARBON 2.2K 5% 1/4W
R519 1-249-528-00 CARBON 100 5% 1/4W
R520 1-249-606-11 CARBON 180K 5% 1/4W
R523 1-247-891-00 CARBON 330K 5% 1/4W
R539 1-259-416-11 CARBON 330 5% 1/6W
R540 1-259-416-11 CARBON 330 5% 1/6W
R541 1-259-416-11 CARBON 330 5% 1/6W
R542 1-259-416-11 CARBON 330 5% 1/6W
R543 1-249-504-11 CARBON 10 5% 1/4W
R550 1-249-917-11 CARBON 560 1% 1/4W
R551 1-249-560-00 CARBON 2.2K 5% 1/4W
R601 1-259-380-11 CARBON 10 5% 1/6W
R602 1-259-380-11 CARBON 10 5% 1/6W
R603 1-259-380-11 CARBON 10 5% 1/6W
R604 1-259-380-11 CARBON 10 5% 1/6W
R605 1-249-455-11 CARBON 4.7 5% 1/4W
R606 1-249-520-11 CARBON 47 5% 1/4W
R608 1-249-911-11 CARBON 330 1% 1/4W
R609 1-249-911-11 CARBON 330 1% 1/4W
R610 1-249-887-11 CARBON 33 1% 1/4W
R611 1-249-887-11 CARBON 33 1% 1/4W
R612 1-249-931-11 CARBON 2.2K 1% 1/4W
R613 1-249-931-11 CARBON 2.2K 1% 1/4W
R614 1-249-933-11 CARBON 2.7K 1% 1/4W
R615 1-249-933-11 CARBON 2.7K 1% 1/4W
R616 1-249-553-11 CARBON 1.1K 5% 1/4W
R617 1-249-560-00 CARBON 2.2K 5% 1/4W
R619 1-249-528-00 CARBON 100 5% 1/4W
R620 1-249-606-11 CARBON 180K 5% 1/4W
R623 1-247-891-00 CARBON 330K 5% 1/4W
R639 1-259-416-11 CARBON 330 5% 1/6W
R640 1-259-416-11 CARBON 330 5% 1/6W
R641 1-259-416-11 CARBON 330 5% 1/6W
R642 1-259-416-11 CARBON 330 5% 1/6W
R643 1-249-504-11 CARBON 10 5% 1/4W
R650 1-249-917-11 CARBON 560 1% 1/4W
R651 1-249-560-00 CARBON 2.2K 5% 1/4W
< RELAY >
RY301 1-515-804-11 RELAY
< TRANSFORMER >
T201 1-409-594-11 COIL (WITH CORE)
< VIBRATOR >
X321 1-579-161-11 VIBRATOR, CRYSTAL (45MHz)
************************************************************
* A-4699-354-A PANEL BOARD, COMPLETE
**********************
< CONNECTOR >
* CN817 1-568-852-11 SOCKET, CONNECTOR 9P
< DIODE >
D801 8-719-303-02 DIODE SEL2510C-D (()
D802 8-719-301-52 DIODE SEL2810A-C (P)
D803 8-719-046-41 DIODE SEL5521C-TP15 (FILTER)
< TRANSISTOR >
Q801 8-729-900-80 TRANSISTOR DTC114ES
Q802 8-729-900-80 TRANSISTOR DTC114ES
Q803 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R801 1-249-415-11 CARBON 680 5% 1/4W
R802 1-249-417-11 CARBON 1K 5% 1/4W
R803 1-249-419-11 CARBON 1.5K 5% 1/4W
R804 1-249-421-11 CARBON 2.2K 5% 1/4W
R805 1-247-843-11 CARBON 3.3K 5% 1/4W
R806 1-249-427-11 CARBON 6.8K 5% 1/4W
R811 1-249-415-11 CARBON 680 5% 1/4W
R812 1-249-417-11 CARBON 1K 5% 1/4W
R813 1-249-419-11 CARBON 1.5K 5% 1/4W
R814 1-249-421-11 CARBON 2.2K 5% 1/4W
R815 1-247-843-11 CARBON 3.3K 5% 1/4W
R816 1-249-427-11 CARBON 6.8K 5% 1/4W
R821 1-249-410-11 CARBON 270 5% 1/4W
R822 1-249-406-11 CARBON 120 5% 1/4W
R823 1-249-410-11 CARBON 270 5% 1/4W
R831 1-249-429-11 CARBON 10K 5% 1/4W
R832 1-249-429-11 CARBON 10K 5% 1/4W
< VARIABLE RESISTOR >
RV801 1-475-006-11 ENCODER, ROTARY
(AMS/≠± PUSH ENTER)
< SWITCH >
S801 1-554-303-21 SWITCH, TACTILE (ERASE)
S802 1-554-303-21 SWITCH, TACTILE (CHECK)
S803 1-554-303-21 SWITCH, TACTILE (CLEAR)
S804 1-554-303-21 SWITCH, TACTILE (FILTER)
S805 1-554-303-21 SWITCH, TACTILE (0)
S806 1-554-303-21 SWITCH, TACTILE ())
S811 1-554-303-21 SWITCH, TACTILE (EDIT/TIME FADE)
S812 1-554-303-21 SWITCH, TACTILE (REPEAT)
S813 1-554-303-21 SWITCH, TACTILE (FILE)
S814 1-554-303-21 SWITCH, TACTILE (§ OPEN/CLOSE)
MAIN PANEL
