Sony CDP-XA30ES - Page 49

– 70 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C612 1-136-802-11 FILM 0.015uF 5% 100V
C615 1-130-973-00 FILM 0.022uF 5% 100V
C616 1-136-850-11 FILM 0.1uF 5% 63V
C617 1-136-850-11 FILM 0.1uF 5% 63V
C618 1-136-850-11 FILM 0.1uF 5% 63V
C619 1-128-198-11 ELECT 22uF 20% 50V
C620 1-128-198-11 ELECT 22uF 20% 50V
C621 1-130-973-00 FILM 0.022uF 5% 100V
C622 1-130-955-00 FILM 0.01uF 5% 100V
C623 1-130-955-00 FILM 0.01uF 5% 100V
C624 1-130-339-11 FILM 0.0056uF 5% 100V
C625 1-130-339-11 FILM 0.0056uF 5% 100V
C626 1-136-814-11 FILM 0.001uF 5% 100V
C627 1-136-814-11 FILM 0.001uF 5% 100V
C630 1-136-817-11 FILM 0.0033uF 2% 100V
C631 1-136-813-11 FILM 680PF 5% 100V
C632 1-128-201-11 ELECT 100uF 20% 50V
C633 1-137-506-11 FILM 0.47uF 10% 63V
C635 1-136-802-11 FILM 0.015uF 5% 100V
C636 1-128-198-51 ELECT 22uF 20% 63V
C637 1-128-201-11 ELECT 100uF 20% 50V
< CONNECTOR >
CN201 1-564-506-11 PLUG, CONNECTOR 3P
* CN301 1-568-835-11 SOCKET, CONNECTOR 16P
CN302 1-564-511-11 PLUG, CONNECTOR 8P
* CN303 1-564-509-11 PLUG, CONNECTOR 6P
CN304 1-564-509-11 PLUG, CONNECTOR 6P
CN305 1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D220 8-719-210-21 DIODE 11EQS04
D221 8-719-210-21 DIODE 11EQS04
D261 8-719-987-31 DIODE 1N4148M
D262 8-719-987-31 DIODE 1N4148M
D263 8-719-987-31 DIODE 1N4148M
D264 8-719-987-31 DIODE 1N4148M
D301 8-719-987-63 DIODE 1N4148M
D302 8-719-109-98 DIODE RD6.8ES-B3
D303 8-719-987-63 DIODE 1N4148M
< IC >
IC208 8-749-921-12 IC GP1F32T (DIGITAL OUT OPTICAL)
IC211 8-759-604-86 IC M5F7807L
IC212 8-759-604-90 IC M5F7907L
IC213 8-759-231-53 IC TA7805S
IC251 8-759-242-70 IC TC7WU04F
IC301 8-759-462-70 IC CXD8679Q
IC302 8-759-454-42 IC CXD2562Q-CS
IC303 8-759-180-84 IC TC7W74F
IC501 8-759-371-51 IC CXA8042AS
IC502 8-759-443-33 IC OPA2132PA
IC503 8-759-259-12 IC OPA2604AP
IC601 8-759-371-51 IC CXA8042AS
IC602 8-759-443-33 IC OPA2132PA
IC603 8-759-259-12 IC OPA2604AP
< JACK >
J301 1-569-443-21 JACK, PIN 4P (LINE OUT)
J351 1-770-905-21 JACK, PIN 1P (DIGITAL OUT COAXIAL)
< COIL >
L251 1-410-322-11 INDUCTOR 3.3uH
L252 1-410-322-11 INDUCTOR 3.3uH
L302 1-410-503-11 INDUCTOR 3.3uH
L303 1-410-322-11 INDUCTOR 3.3uH
L304 1-410-970-11 INDUCTOR 6.8uH
L504 1-412-473-21 INDUCTOR 0uH
L505 1-412-473-21 INDUCTOR 0uH
L604 1-412-473-21 INDUCTOR 0uH
L605 1-412-473-21 INDUCTOR 0uH
< FILTER >
LPF201 1-424-153-11 FILTER, NOISE
LPF202 1-424-153-11 FILTER, NOISE
LPF301 1-424-153-11 FILTER, NOISE
< TRANSISTOR >
Q301 8-729-900-65 TRANSISTOR DTA144ES
< RESISTOR >
R254 1-249-393-11 CARBON 10 5% 1/4W
R255 1-249-417-11 CARBON 1K 5% 1/4W
R256 1-249-401-11 CARBON 47 5% 1/4W
R257 1-249-393-11 CARBON 10 5% 1/4W
R258 1-249-417-11 CARBON 1K 5% 1/4W
R259 1-249-417-11 CARBON 1K 5% 1/4W
R260 1-249-417-11 CARBON 1K 5% 1/4W
R262 1-249-401-11 CARBON 47 5% 1/4W
R263 1-249-393-11 CARBON 10 5% 1/4W
R301 1-249-437-11 CARBON 47K 5% 1/4W
R302 1-249-417-11 CARBON 1K 5% 1/4W
R303 1-249-417-11 CARBON 1K 5% 1/4W
R306 1-249-409-11 CARBON 220 5% 1/4W
R307 1-249-417-11 CARBON 1K 5% 1/4W
R310 1-249-441-11 CARBON 100K 5% 1/4W
R311 1-249-417-11 CARBON 1K 5% 1/4W
R312 1-249-417-11 CARBON 1K 5% 1/4W
R313 1-249-411-11 CARBON 330 5% 1/4W
R314 1-249-417-11 CARBON 1K 5% 1/4W
R315 1-249-411-11 CARBON 330 5% 1/4W
R316 1-249-441-11 CARBON 100K 5% 1/4W
R317 1-249-409-11 CARBON 220 5% 1/4W
R321 1-249-429-11 CARBON 10K 5% 1/4W
¡ R351 1-217-997-11 FUSIBLE 10 5% 1/2W F
MAIN
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
