ā 68 ā
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< VIBRATOR >
X351 1-577-358-21 VIBRATOR, CERAMIC (4MHz)
************************************************************
* 1-663-580-11 BD TRANSLATION BOARD
*********************
< CONNECTOR >
* CN108 1-568-933-11 SOCKET, CONNECTOR 30P
CN109 1-774-380-11 CONNECTOR, FFC/FPC 16P
CN110 1-580-864-11 SOCKET, CONNECTOR (SMT) 10P
< SWITCH >
SW102 1-571-958-11 SWITCH, PUSH (1 KEY) (LIMIT SW)
************************************************************
A-4699-360-A BSL BOARD, COMPLETE
********************
1-580-881-11 SOCKET, CONNECTOR (SMT) 10P
< DIODE >
H11 8-719-987-62 DIODE LT140SAZ
H12 8-719-987-62 DIODE LT140SAZ
< RESISTOR >
R01 1-216-295-00 CONDUCTOR, CHIP (2012)
R02 1-216-295-00 CONDUCTOR, CHIP (2012)
R11 1-216-049-00 METAL GLAZE 1K 5% 1/10W
R12 1-216-049-00 METAL GLAZE 1K 5% 1/10W
************************************************************
* A-4699-353-A DISPLAY BOARD, COMPLETE
************************
* 4-969-510-01 HOLDER (FL)
< CAPACITOR >
C801 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C802 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C803 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C804 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C805 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C806 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C807 1-163-031-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN810 1-568-853-11 SOCKET, CONNECTOR 10P
< FLUORECENT INDICATOR >
FLD801 1-517-357-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 8-759-324-36 IC LC7570E
IC802 8-759-324-36 IC LC7570E
IC803 8-759-324-36 IC LC7570E
IC804 8-759-373-48 IC NJL53H400
< TRANSISTOR >
Q804 8-729-424-18 TRANSISTOR UN2113-TX
Q805 8-729-421-19 TRANSISTOR UN2213
< RESISTOR >
R817 1-216-045-00 METAL CHIP 680 5% 1/10W
R827 1-216-029-00 METAL CHIP 150 5% 1/10W
R828 1-216-089-00 METAL GLAZE 47K 5% 1/10W
R829 1-216-097-00 METAL GLAZE 100K 5% 1/10W
< SWITCH >
S819 1-554-303-21 SWITCH, TACTILE (P MODE)
S820 1-554-303-21 SWITCH, TACTILE (TIME)
************************************************************
* A-4699-566-A HP BOARD, COMPLETE (BLACK)
* A-4699-710-A HP BOARD, COMPLETE (GOLD)
**************************
< CAPACITOR >
C365 1-126-012-11 ELECT 470uF 20% 16V
C366 1-126-012-11 ELECT 470uF 20% 16V
C405 1-164-159-11 CERAMIC 0.1uF 50V
C550 1-162-294-31 CERAMIC 0.001uF 10% 50V
C650 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
CN402 1-564-523-11 PLUG, CONNECTOR 8P
CN407 1-564-524-11 PLUG, CONNECTOR 9P
< IC >
IC354 8-759-962-08 IC BA6208
IC356 8-759-981-85 IC RC4556D
< JACK >
J401 1-750-162-61 JACK (LARGE TYPE) (PHONES) (BLACK)
J401 1-779-219-11 JACK (LARGE TYPE) (PHONES) (GOLD)
< COIL >
L310 1-412-473-21 INDUCTOR 0uH
L311 1-412-473-21 INDUCTOR 0uH
L503 1-412-473-21 INDUCTOR 0uH
L603 1-412-473-21 INDUCTOR 0uH
< TRANSISTOR >
Q504 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q604 8-729-141-30 TRANSISTOR 2SC3623A-LK
< RESISTOR >
R369 1-247-807-31 CARBON 100 5% 1/4W
R370 1-247-807-31 CARBON 100 5% 1/4W
R532 1-249-441-11 CARBON 100K 5% 1/4W
R533 1-247-890-11 CARBON 300K 5% 1/4W
R534 1-249-441-11 CARBON 100K 5% 1/4W
R535 1-247-890-11 CARBON 300K 5% 1/4W
R536 1-249-402-11 CARBON 56 5% 1/4W
R537 1-249-425-11 CARBON 4.7K 5% 1/4W
R632 1-249-441-11 CARBON 100K 5% 1/4W
R633 1-247-890-11 CARBON 300K 5% 1/4W
BD BD TRANSLATION BSL DISPLAY HP
