Sony CDP-XA30ES - Vol Sel Parts List

– 73 –
* 1-663-576-13 VOL SEL BOARD
*************
< CAPACITOR >
¡ C992 1-113-916-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
CN991 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN992 1-564-321-00 PIN, CONNECTOR 2P
CN993 1-770-128-11 PIN, CONNECTOR 2P
* CN995 1-564-321-21 PIN, CONNECTOR 2P (Singapore)
< SWITCH >
¡ S992 1-571-722-11 SWITCH, VOLTAGE SELECTION
(VOLTAGE SELECTOR) (Singapore)
< LINE FILTER >
¡ T603 1-424-485-11 FILTER, LINE
************************************************************
MISCELLANEOUS
**************
6 1-777-844-11 WIRE (FLAT TYPE) (9 CORE)
7 1-777-845-11 WIRE (FLAT TYPE) (10 CORE)
105 1-777-873-11 WIRE (FLAT TYPE) (16 CORE)
114 1-543-653-11 CORE ASSY, BEAD (DIVISION TYPE)
162 1-777-843-11 WIRE (FLAT TYPE) (30 CORE)
209 1-775-991-11 WIRE (FLAT TYPE) (16 CORE)
¡ 210 8-848-379-31 OPTICAL PICK-UP KSS-213B/S-N
221 1-777-842-11 WIRE (FLAT TYPE) (10 CORE)
¡ CNP1 1-558-568-21 CORD, POWER
M1 X-4947-303-1 MOTOR ASSY (SLED)
M2 A-4640-970-A MOTOR ASSY (SLED)
¡ T1 1-431-214-11 TRANSFORMER, POWER (Singapore)
¡ T1 1-431-215-11 TRANSFORMER, POWER (AEP)
***********************************************************
**************
HARDWARE LIST
**************
#1 7-685-871-09 SCREW +BVTP 3X6 (S)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-871-01 SCREW +BVTP 3X6 (S)
#4 7-685-885-09 SCREW +BVTP 4X16 (S)
#5 7-621-770-67 SCREW +PWH 2.6X6
#6 7-685-872-09 SCREW +BVTP 3X8 (S)
#7 7-627-852-07 SCREW, RECISION +P 1.7X2.5
***********************************************************
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
VOL SEL
ACCESSORIS & PACKING MATERIALS
******************************
1-473-944-11 REMOTE COMMANDER (RM-D950)
1-590-925-31 CORD, CONNECTION (AUDIO 100cm)
3-707-584-21 COVER, BATTERY (for RM-D950)
(ENGLISH, FRENCH, SPANISH, SWEDISH)
3-858-365-21 MANUAL, INSTRUCTION (GERMAN, DUTCH,
ITALIAN, PORTUGUESE) (AEP)
3-858-365-31 MANUAL, INSTRUCTION (CHINESE)
(Singapore)
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
