– 49 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
SERVO
C36 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C37 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C38 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C39 1-126-204-11 ELECT CHIP 47uF 20% 16V
C40 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN1 1-764-616-12 HOUSING,CONNECTOR(PC BOARD)30P
CN2 1-565-728-51 CONNECTOR, FPC 17P
CN3 1-770-347-21 CONNECTOR, FPC 6P
< IC >
IC1 8-752-372-94 IC CXD2507AQ
IC2 8-752-074-34 IC CXA1782BQ
IC3 8-759-354-16 IC BA6796FP-T1
< JUMPER RESISTOR >
JR1 1-216-296-00 SHORT 0
JR2 1-216-296-00 SHORT 0
JR3 1-216-296-00 SHORT 0
JR4 1-216-296-00 SHORT 0
JR5 1-216-296-00 SHORT 0
JR6 1-216-296-00 SHORT 0
JR7 1-216-296-00 SHORT 0
JR8 1-216-296-00 SHORT 0
JR9 1-216-296-00 SHORT 0
JR10 1-216-296-00 SHORT 0
JR11 1-216-296-00 SHORT 0
JR12 1-216-296-00 SHORT 0
JR13 1-216-296-00 SHORT 0
JR14 1-216-296-00 SHORT 0
JR15 1-216-296-00 SHORT 0
JR16 1-216-296-00 SHORT 0
JR17 1-216-296-00 SHORT 0
JR18 1-216-296-00 SHORT 0
JR19 1-216-296-00 SHORT 0
JR20 1-216-296-00 SHORT 0
JR21 1-216-296-00 SHORT 0
JR22 1-216-296-00 SHORT 0
JR23 1-216-296-00 SHORT 0
JR24 1-216-296-00 SHORT 0
JR25 1-216-296-00 SHORT 0
JR26 1-216-296-00 SHORT 0
JR27 1-216-296-00 SHORT 0
JR28 1-216-296-00 SHORT 0
JR29 1-216-296-00 SHORT 0
JR30 1-216-296-00 SHORT 0
JR31 1-216-296-00 SHORT 0
JR32 1-216-296-00 SHORT 0
JR33 1-216-296-00 SHORT 0
JR34 1-216-296-00 SHORT 0
JR35 1-216-296-00 SHORT 0
JR36 1-216-296-00 SHORT 0
JR37 1-216-296-00 SHORT 0
JR38 1-216-296-00 SHORT 0
JR39 1-216-296-00 SHORT 0
JR40 1-216-296-00 SHORT 0
JR41 1-216-296-00 SHORT 0 (CDX-2250)
JR43 1-216-296-00 SHORT 0
JR44 1-216-296-00 SHORT 0
JR45 1-216-296-00 SHORT 0
JR46 1-216-296-00 SHORT 0
< COIL >
L1 1-412-058-11 INDUCTOR CHIP 10uH
L2 1-412-058-11 INDUCTOR CHIP 10uH
L3 1-412-058-11 INDUCTOR CHIP 10uH
< TRANSISTOR >
Q1 8-729-904-60 TRANSISTOR DTB113ZK
Q2 8-729-904-86 TRANSISTOR 2SB1197K-Q
< RESISTOR >
R1 1-216-073-00 METAL CHIP 10K 5% 1/10W
R2 1-216-097-00 RES,CHIP 100K 5% 1/10W
R3 1-216-121-00 RES,CHIP 1M 5% 1/10W
R4 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R5 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R6 1-216-073-00 METAL CHIP 10K 5% 1/10W
R7 1-216-009-00 RES,CHIP 22 5% 1/10W
R8 1-216-119-00 METAL CHIP 820K 5% 1/10W
R9 1-216-119-00 METAL CHIP 820K 5% 1/10W
R10 1-216-073-00 METAL CHIP 10K 5% 1/10W
R11 1-216-073-00 METAL CHIP 10K 5% 1/10W
R14 1-216-085-00 METAL CHIP 33K 5% 1/10W
R15 1-216-085-00 METAL CHIP 33K 5% 1/10W
R16 1-216-077-00 METAL CHIP 15K 5% 1/10W
R17 1-216-081-00 METAL CHIP 22K 5% 1/10W
R19 1-216-079-00 METAL CHIP 18K 5% 1/10W
R20 1-216-105-00 RES,CHIP 220K 5% 1/10W
R21 1-216-105-00 RES,CHIP 220K 5% 1/10W
R22 1-216-085-00 METAL CHIP 33K 5% 1/10W
R23 1-216-121-00 RES,CHIP 1M 5% 1/10W
R24 1-216-073-00 METAL CHIP 10K 5% 1/10W
R27 1-216-295-00 SHORT 0
R28 1-216-101-00 METAL CHIP 150K 5% 1/10W
R29 1-216-097-00 RES,CHIP 100K 5% 1/10W
R30 1-216-097-00 RES,CHIP 100K 5% 1/10W
R31 1-216-081-00 METAL CHIP 22K 5% 1/10W
R32 1-216-109-00 METAL CHIP 330K 5% 1/10W
R33 1-216-105-00 RES,CHIP 220K 5% 1/10W
R34 1-216-009-00 RES,CHIP 22 5% 1/10W
R35 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R36 1-216-097-00 RES,CHIP 100K 5% 1/10W
R37 1-216-117-00 METAL CHIP 680K 5% 1/10W
R38 1-216-109-00 METAL CHIP 330K 5% 1/10W
R39 1-216-101-00 METAL CHIP 150K 5% 1/10W
R40 1-216-114-00 RES,CHIP 510K 5% 1/10W
R41 1-216-093-00 RES,CHIP 68K 5% 1/10W
R42 1-216-103-00 METAL CHIP 180K 5% 1/10W
R43 1-216-097-00 RES,CHIP 100K 5% 1/10W
R44 1-216-085-00 METAL CHIP 33K 5% 1/10W
R45 1-216-081-00 METAL CHIP 22K 5% 1/10W
R45 1-216-089-00 RES,CHIP 47K 5% 1/10W
R46 1-216-097-00 RES,CHIP 100K 5% 1/10W
