Sony CX-JT7 - Front Panel Section; Mechanical Deck

CX-JT7
12
3-6. FRONT PANEL SECTION
3-7. MECHANICAL DECK
2 connector (CN310)
4 connector (CN203)
3 connector (CN202)
5 wire (flat type) (9 core)
(CN311)
7 front panel section
6 three screws
(BVTP3
× 10)
1 wire (flat type) (31 core)
(CN304)
3 mechanical deck
1 wire (flat type) (13core)
2 six screws
(BVTP3
× 10
)
4 ground mechanical plate
