Sony CX-JT7 - (Cdm74 F-K6 Bd71 A)

72
CX-JT7
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
601 X-4955-707-1 PULLEY (A5) ASSY, CHUCKING
602 1-471-035-11 MAGNET ASSY
603 4-231-189-01 PULLEY (B), CHUCKING
604 4-218-252-61 SCREW (+PTPWH M2.6), FLOATING
605 4-243-822-01 LEVER (LIFTER)
606 X-4955-536-1 HOLDER (213) ASSY
607 4-227-549-11 INSULATOR
608 4-227-045-31 SPRING (INSULATOR), COIL
609 4-231-151-01 STOPPER (BU)
610 4-218-253-31 SCREW (M2.6), +BTTP
612 4-243-817-01 CHASSIS
602
603
601
604
604
605
606
612
607
608
609
610
BU-K6BD71A
7-10. CD MECHANISM DECK SECTION-3
(CDM74F-K6BD71A)
