• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
Set
3-2. CASE
(SIDE-L/R)
(Page 10)
3-3. CASE (TOP)
(Page 10)
3-4. TRAY PANEL
(Page 11)
3-6. FRONT PANEL
SECTION
(Page 12)
3-8. REAR CABINET
SECTION
(Page 13)
3-7. MECHANICAL
DECK
(Page 12)
3-9. MAIN BOARD
(Page 13)
3-10. POWER
BOARD
(Page 14)
3-11. TRANSFORMER BOARD
(Page 14)
3-16. MOTOR GEAR ASSY (SLED) (M701),
BD BOARD
(Page 17)
3-17. OPTICAL PICK-UP
(KSS-213D)
(Page 17)
3-15. BASE UNIT
(BU-K6BD71A)
(Page 16)
3-12. TABLE ASSY
(Page 15)
3-13. MOTOR (TB)
BOARD
(Page 15)
3-14. MOTOR (LD)
BOARD
(Page 16)
3-5. CD MECHANISM DECK
(CDM74F-K6BD71A)
(Page 11)
Note 1: The process described in can be performed in any order.
Note 2: Without completing the process described in , the next process can not be performed.
