Sony CX-JT7 - Page 78

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
78
CX-JT7
CN307 1-778-982-21 CONNECTOR, BOARD TO BOARD 13P
CN310 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN311 1-568-828-11 CONNECTOR, FFC 9P
CN312 1-784-780-11 CONNECTOR, FFC 19P
< DIODE/SHORT >
D101 8-719-988-61 DIODE 1SS355TE-17 (AEP, UK)
D102 6-500-522-21 DIODE 10EDB40-TB3
D205 8-719-988-61 DIODE 1SS355TE-17
D206 8-719-988-61 DIODE 1SS355TE-17
D301 6-500-522-21 DIODE 10EDB40-TB3
D302 6-500-522-21 DIODE 10EDB40-TB3
D303 6-500-522-21 DIODE 10EDB40-TB3
D304 6-500-522-21 DIODE 10EDB40-TB3
D305 8-719-988-61 DIODE 1SS355TE-17
D306 8-719-988-61 DIODE 1SS355TE-17
D307 8-719-988-61 DIODE 1SS355TE-17
D308 1-216-295-00 SHORT CHIP 0
D311 8-719-988-61 DIODE 1SS355TE-17
D312 8-719-083-63 DIODE UDZSTE-1713B
D313 6-500-522-21 DIODE 10EDB40-TB3
D314 6-500-522-21 DIODE 10EDB40-TB3
D315 6-500-522-21 DIODE 10EDB40-TB3
D316 6-500-522-21 DIODE 10EDB40-TB3
D317 8-719-988-61 DIODE 1SS355TE-17
D319 6-500-522-21 DIODE 10EDB40-TB3
D320 6-500-522-21 DIODE 10EDB40-TB3
D321 6-500-522-21 DIODE 10EDB40-TB3
D322 6-500-522-21 DIODE 10EDB40-TB3
D324 8-719-988-61 DIODE 1SS355TE-17 (SUFFIX-13)
D364 8-719-988-61 DIODE 1SS355TE-17
D371 8-719-988-61 DIODE 1SS355TE-17
D372 8-719-988-61 DIODE 1SS355TE-17
D374 8-719-988-61 DIODE 1SS355TE-17
< GROUND TERMINAL >
* GA1 1-537-738-21 TERMINAL, EARTH
< IC >
IC201 6-702-130-01 IC HA12237F
IC301 6-703-650-11 IC M61529FP-D60G
IC303 6-704-074-01 IC NJM2156M (TE2)
IC304 8-759-710-97 IC NJM4565M-D
IC305 8-759-701-59 IC NJM78M09FA
IC306 6-701-760-01 IC uPC3504AHF
IC308 8-759-701-59 IC NJM78M09FA
IC309 6-704-046-01 IC BU2099FV
IC310 6-704-046-01 IC BU2099FV
IC313 8-759-231-57 IC TA7810S
< JACK >
JK302 1-793-987-11 JACK, PIN 2P (MD (VIDEO) IN)
< SHORT >
JR124 1-216-864-11 SHORT CHIP 0 (AEP, UK, CIS)
JR300 1-216-864-11 SHORT CHIP 0
JR302 1-216-864-11 SHORT CHIP 0 (SUFFIX-11)
JR303 1-216-864-11 SHORT CHIP 0
JR304 1-216-864-11 SHORT CHIP 0
JR305 1-216-864-11 SHORT CHIP 0
JR306 1-216-864-11 SHORT CHIP 0
JR307 1-216-864-11 SHORT CHIP 0
JR308 1-216-864-11 SHORT CHIP 0
JR309 1-216-864-11 SHORT CHIP 0
JR310 1-216-864-11 SHORT CHIP 0
JR311 1-216-864-11 SHORT CHIP 0
JR312 1-216-864-11 SHORT CHIP 0
JR313 1-216-864-11 SHORT CHIP 0
JR314 1-216-864-11 SHORT CHIP 0 (MX, E51) (SUFFIX-13)
JR316 1-216-864-11 SHORT CHIP 0
JR317 1-216-864-11 SHORT CHIP 0
JR321 1-216-864-11 SHORT CHIP 0
JR322 1-216-864-11 SHORT CHIP 0
JR325 1-216-864-11 SHORT CHIP 0
JR326 1-216-864-11 SHORT CHIP 0
JR328 1-216-864-11 SHORT CHIP 0
JR333 1-216-864-11 SHORT CHIP 0
JR334 1-216-864-11 SHORT CHIP 0 (MX, E51)
JR336 1-216-864-11 SHORT CHIP 0
JR337 1-216-864-11 SHORT CHIP 0
JR339 1-216-864-11 SHORT CHIP 0
JR341 1-216-864-11 SHORT CHIP 0
JR343 1-216-864-11 SHORT CHIP 0 (SUFFIX-13)
< TRANSFORMER >
L201 1-437-220-11 TRANSFORMER, BIAS OSCILLATION
< TRANSISTOR >
Q218 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q219 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q220 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q221 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q222 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q223 8-729-142-46 TRANSISTOR 2SC2001-LK
Q225 6-550-289-01 TRANSISTOR 2SA1235F
Q228 8-729-140-04 TRANSISTOR 2SB1116A-L
Q301 6-550-296-01 TRANSISTOR 2SA1980G
Q302 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q304 8-729-041-19 TRANSISTOR 2SA953-T-K
Q310 8-729-052-79 TRANSISTOR 2SD1306NETL
Q311 8-729-052-79 TRANSISTOR 2SD1306NETL
Q312 6-550-289-01 TRANSISTOR 2SA1235F
Q314 8-729-045-62 FET 2SK2158-T2B
Q315 8-729-045-62 FET 2SK2158-T2B
Q316 8-729-045-62 FET 2SK2158-T2B
Q317 8-729-045-62 FET 2SK2158-T2B
Q318 8-729-045-62 FET 2SK2158-T2B
Q319 8-729-045-62 FET 2SK2158-T2B
Q320 8-729-045-62 FET 2SK2158-T2B
Q323 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q324 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q327 6-550-289-01 TRANSISTOR 2SA1235F
Q328 8-729-041-19 TRANSISTOR 2SA953-T-K
Q330 8-729-120-28 TRANSISTOR 2SC1623-L5L6
MAIN
