Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
89
CX-JT7
R550 1-216-817-11 METAL CHIP 470 5% 1/10W
(MX, E51)
R550 1-216-818-11 METAL CHIP 560 5% 1/10W
(AEP, UK, CIS)
R553 1-216-838-11 METAL CHIP 27K 5% 1/10W
R554 1-216-838-11 METAL CHIP 27K 5% 1/10W
R555 1-216-841-11 METAL CHIP 47K 5% 1/10W
R556 1-216-841-11 METAL CHIP 47K 5% 1/10W
R557 1-216-821-11 METAL CHIP 1K 5% 1/10W
R558 1-216-821-11 METAL CHIP 1K 5% 1/10W
R559 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R560 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R561 1-216-843-11 METAL CHIP 68K 5% 1/10W
R562 1-216-857-11 METAL CHIP 1M 5% 1/10W
R563 1-216-214-00 RES-CHIP 4.7K 5% 1/8W
R564 1-216-214-00 RES-CHIP 4.7K 5% 1/8W
R567 1-216-214-00 RES-CHIP 4.7K 5% 1/8W
R568 1-216-214-00 RES-CHIP 4.7K 5% 1/8W
R569 1-216-853-11 METAL CHIP 470K 5% 1/10W
R570 1-260-076-21 CARBON 10 5% 1/2W
R571 1-260-076-21 CARBON 10 5% 1/2W
R572 1-216-156-00 RES-CHIP 18 5% 1/8W
R573 1-216-156-00 RES-CHIP 18 5% 1/8W
R574 1-216-182-00 RES-CHIP 220 5% 1/8W
R575 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R576 1-216-837-11 METAL CHIP 22K 5% 1/10W
R577 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R578 1-216-182-00 RES-CHIP 220 5% 1/8W
R579 1-216-156-00 RES-CHIP 18 5% 1/8W
R580 1-216-150-11 RES-CHIP 10 5% 1/8W
R581 1-216-246-00 RES-CHIP 100K 5% 1/8W
R582 1-216-156-00 RES-CHIP 18 5% 1/8W
R589 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R591 1-216-841-11 METAL CHIP 47K 5% 1/10W
R592 1-216-835-11 METAL CHIP 15K 5% 1/10W
R593 1-216-833-11 METAL CHIP 10K 5% 1/10W
R594 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R595 1-216-361-00 METAL OXIDE 0.22 5% 2W F
(AEP, UK, CIS)
0 R596 1-216-361-00 METAL OXIDE 0.22 5% 2W F
(AEP, UK, CIS)
0 R597 1-216-361-00 METAL OXIDE 0.22 5% 2W F
(AEP, UK, CIS)
0 R598 1-216-361-00 METAL OXIDE 0.22 5% 2W F
(AEP, UK, CIS)
R599 1-216-841-11 METAL CHIP 47K 5% 1/10W
R601 1-216-156-00 RES-CHIP 18 5% 1/8W
R602 1-216-156-00 RES-CHIP 18 5% 1/8W
R603 1-216-156-00 RES-CHIP 18 5% 1/8W
R604 1-216-156-00 RES-CHIP 18 5% 1/8W
< RELAY >
RY501 1-755-308-11 RELAY
< THERMISTOR >
TH501 1-805-217-11 THERMISTOR (1012)
TH502 1-805-217-11 THERMISTOR (1012)
**************************************************************
POWER SENSOR SW TRANSFORMER
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
1-687-132-11 SENSOR BOARD
*************
< CONNECTOR >
CN731 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE) 3P
< IC >
IC731 (not supplied)
**************************************************************
1-687-669-11 SW BOARD
*********
< SWITCH >
S751 1-786-514-11 SWITCH, LEVER (SLIDE)
(OPEN/CLOSE DETECT)
**************************************************************
1-688-695-13 TRANSFORMER BOARD (AEP, UK, CIS)
1-688-747-13 TRANSFORMER BOARD (E51)
1-688-958-11 TRANSFORMER BOARD (MX)
*******************
* 1-533-213-31 FUSE HOLDER
< CAPACITOR >
C901 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C902 1-126-941-11 ELECT 470uF 20% 25V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN902 1-764-334-11 PLUG, CONNECTOR 11P
< DIODE >
D901 8-719-988-61 DIODE 1SS355TE-17 (E51)
D902 8-719-988-61 DIODE 1SS355TE-17
D903 8-719-988-61 DIODE 1SS355TE-17
D904 8-719-988-61 DIODE 1SS355TE-17
D905 8-719-988-61 DIODE 1SS355TE-17
D906 8-719-988-61 DIODE 1SS355TE-17 (EXCEPT E51)
< TRANSFORMER >
0 PT902 1-439-735-11 TRANSFORMER, POWER (AEP, UK, CIS)
0 PT902 1-439-736-11 TRANSFORMER, POWER (E51)
0 PT902 1-439-944-11 TRANSFORMER, POWER (MX)
< RELAY >
0 RY901 1-755-496-11 RELAY (E51)
0 RY902 1-755-276-11 RELAY, POWER (EXCEPT E51)
< SWITCH >
0 S901 1-786-408-11 SW, SL 1-2-3 SWS2301 (AC VOLTAGE) (E51)
************************************************************
