Sony DCR-TRV890E - Cabinet (Upper) Assembly, Front Panel Assembly

2-1
DCR-TRV890E/TRV900/TRV900E
SECTION 2
DISASSEMBLY
NOTE: Follow the disassembly procedure as shown in the flow chart below.
2-1. CABINET (UPPER) ASSEMBLY, FRONT PANEL ASSEMBLY
NOTE: Follow the disassembly procedure in the numerical order given.
DCR-TRV890E/TRV900/TRV900E
2-1. Cabinet (upper) assembly, Front panel assembly
2-2. Battery panel assembly
2-3. Cabinet (R) assembly, Cabinet (L) assembly
2-5 JK-163 board
2-6. CK-80 board
2-7. Hinge assembly
2-8. PD-101 board
2-9. BT terminal board DC-IN connector
Lens assembly
2-4.
1 - 5
2-12. MA-333 board
ED-48 board
2-10.
1 - 4
VF-121 board
2-10.
5 - !£
2-11. LB-55 board
VC-208 board
2-4.
6 - @º
VI-151 board
2-4.
!£ - @º
Mechanism deck
2-4.
@¡ - @£
SE-75 board
2-4.
@¢ - @¶
!º Two screws (M2 × 4)
1 Screw (M2 × 4)
2 Screw (M2 × 4)
9 Open the jack cover and
remove the screw (M2 × 4).
5 FP-17 flexible board
CN7203 6P (CK-80 board)
!™ FP-12 flexible board
CN7304 26P (MA-333 board) !¡ Front panel assembly
(Remove it while being
careful of the claw a .)
a
a
4
Screw (M2 × 4)
8 Cabinet (upper) assembly
3 Screw (M2 × 4)
7 FP-10 flexible board
CN2905 20P (VI-151 board)
6 Flexible board
CN7207 24P (CK-80 board)
