6-6
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
251 3-051-905-01 SHEET METAL (LOWER), STRAP
252 1-694-411-11 TERMINAL BOARD, BATTERY
253 X-3949-001-1 PANEL ASSY, BATTERY
254 3-948-339-01 SCREW, TAPPING B2
255 X-3948-957-1 DOOR ASSY, PM
256 3-713-791-71 SCREW (M1.7X4)
257 3-051-951-01 COVER, BT LOCK
258 3-052-017-01 SPRING, BT LOCK
259 3-051-950-01 CLAW, BT LOCK
260 3-968-729-71 SCREW (M2), LOCK ACE, P2
261 1-785-247-11 CONNECTOR, DC-IN
262 3-051-915-01 PLATE, DC FIXED
263 1-670-985-21 FP-18 FLEXIBLE BOARD
264 3-051-917-01 HOLDER, AL KNOB
265 3-051-916-01 KNOB, AL
253
255
256
257
258
259
254
252
251
265
254
264
263
254
254
262
261
260
not supplied
6-1-6. BATTERY PANEL SECTION
