Sony DCR-TRV890E - Flexible Boards Location

2-9E
FP-17
FK-4880
(USER CONTROL)
FP-23
(S-Y/C IN/OUT)
FP-16
FP-11
FP-13
FP-8
FP-19
(USER CONTROL)
For LED
FP-18
(USER CONTROL
)
LENS BLOCK
FP-10
FP-21
(FOCUS)
FP-22
(MIC JACK)
FP-12
FP-37
FP-14
(From VIDEO HEAD)
(From DRUM MOTOR)
From LOADING MOTOR,
S/T REEL SENSOR
FP-9
FP-20
(From CAPSTAN MOTOR)
2-15.FLEXIBLE BOARDS LOCATION
