2-2
2-2. BATTERY PANEL ASSEMBLY
2-3. CABINET (R) ASSEMBLY, CABINET (L) ASSEMBLY
7
Screw (M2
×
4)
9
Control switch block (FK-4880),
CN2907 18P (VI-151 board)
1
FP-9 flexible board
CN2906 60P (VI-151 board)
4
Two screws (M2(step))
1
-
3
Cabinet (R) assembly
4
-
!¡
Cabinet (L) assembly
!¡
Cabinet (L) assembly
3
Cabinet (R) assembly
!º
FP-12 flexible board
CN2902 27P (VI-151 board)
2
FP-13 flexible board
CN761 60P (VC-208 board)
8
Screw
(M2
×
4)
5
Cassette lid
6
Screw
(M2
×
4)
Mechanism deck, lens assembly
1
Screw (M2
×
4)
2
Two screws (M2
×
4)
8
Cable 3P, CN3201 3P (VI-151 board)
9
Cable CN3200 4P (VI-151 board)
7
FP-18 flexible board CN7210 8P (CK-80 board)
6
Battery panel assembly
3
Screw (M2
×
4)
5
Three screws (M2
×
4)
Cabinet (R) assembly
4
CPC cover
Remove it by opening to a
side a little together with the
cabinet (R) assembly)
To Next Page
