Sony DCR- - Quick Reference: Parts and Controls

256
— Quick Reference —
Identifying parts and controls
1 Lens cap (p. 30)
2 LCD screen (p. 30)
3 OPEN button (p. 30)
4 VOLUME –/+ * button (p. 45)
5 Rechargeable Battery Pack (p. 18)
6 BATT (battery) release lever (p. 18)
7 POWER switch (p. 30)
8 START/STOP button (p. 30)
9 Hooks for shoulder strap
0 DC IN jack (p. 19)
* This button has a tactile dot.
Attaching the shoulder strap
Attach the shoulder strap supplied with your camcorder to the hooks for the shoulder
strap.
Camcorder
4
3
2
7
8
9
0
1
6
5
