Identifying parts and controls
rf Viewfinder (p. 35)
rg LOCK switch * (p. 30)
rh Grip strap
rj MIC (PLUG IN POWER) jack (red) *
Connect an external microphone
(optional). This jack also accepts a
“plug-in-power” microphone.
rh
rg
rf
rj
rk
rk LANC jack (blue) *
LANC stands for Local Application
Control Bus System. The LANC control
jack is used for controlling the tape
transport of video equipment and other
peripherals connected to the video
equipment. This jack has the same
function as the jack indicated as
CONTROL L or REMOTE.
*
Fastening the grip strap
Fasten the grip strap firmly.
