Chaper 1 Overview
Chaper 1 Overview
Music Production
Personal computer
Direct box
Keyboard
Microphones
Effect processors (analog)
MIDI multi-port box
from MIDI OUT
to MIDI IN
to LINE IN
to IN A
to INSERTION
(INPUT/OUTPUT)
from AUX SEND
to AUX RET
to 2TR IN
from PGM
from CR MONITOR
to the slot
(DMBK-R106)
Digital reverb
Effect processor (digital)
DAT
Monitor speakers
ADAT
ADAT
ADAT
Connection Examples
