MIDI
MIDI Implementation Chart
Function Transmitted Recognized Remarks
Basic: At power on 1 to 16, OFF 1 to 16, OFF Memorized after the power off.
Channel: Assignable 1 to 16, OFF 1 to 16, OFF
Mode: At power on ××
Message ××
Altered ********** ×
Note ××
Number True voice ********** ×
Velocity: Note ON ××
Note OFF ××
After touch Keys ××
Channels ××
Pitch Bend ××
Control change 0-102 aaRefer to the control change table.
Assignable 0/127
Program change aa
Assignable
System Exclusive ××
System common: Song position ××
Song select ××
Tune ××
Real time: Clock ××
Command ××
Others Local ON/OFF ××
All note OFF ××
Active sensing ××
Reset ××
Remarks:
Mode 1: OMNI ON, POLI
Mode 2: OMNI OFF, MONO
Mode 3: OMNI OFF, POLI
Mode 4: OMNI OFF, MONO
a: Yes
×: No

Sony DMX-R100 Specifications

General

Type	Digital Mixing Console
Bit Depth	24-bit
Aux Sends	8
Surround Sound	Yes
Analog I/O	XLR, TRS
Sampling Rate	44.1 kHz, 48 kHz, 96 kHz
Outputs	24 Analog, 24 Digital
Effects	Built-in DSP effects
EQ	4-band parametric EQ per channel
Faders	100 mm motorized faders
Metering	LED level metering
Automation	Yes
Frequency Response	20 Hz - 20 kHz
Digital I/O	AES/EBU, ADAT
Power Supply	100-240V AC
