Chapter 2 Locations and Functions of Parts and Controls
Chapter 2 Locations and Functions of Parts and Controls
Analog Head Amplifier panel (13)
Master panel (23)
Channel Strip panel (14)
Channel Fader
Assignment panel (17)
Parameter Setting panel (18)
Floppy disk drive
Headphones connector (23)
Automation
panel (26)
Locations and Functions of Parts and Controls
Composition of the Front Panel
For details, refer to pages indicated in parentheses.
Talk-Back panel (16)
Channel Meter panel (13)
Display section (18)
