Sony FMP-X10 - Standby LED Blinking Flowchart

FMP-X10 11
SECTION 1 - TROUBLESHOOTING
STANDBY LED BLINKING FLOWCHART
Protect
Shutdown.
Standby LED
Blinking
Check IC4000
No
Yes
2x
3x
1x
5x,6x,8x,9x
10x
7x
Check FAN, Temp sensor(IC306)
Check IC9000
Check Power Supply for IC9000
(3.3V, 1.8V,1.5V,1.0V)
Check Power Supply for Digital
circuit (12V: Ref IC9706 )
Check HDMI Tx (IC3150)
Yes
Yes
Yes
Yes
Yes
No
No
No
No
*For Device Allocation information, refer to “Section 4 - Diagrams” on page 24.
