SECTION 4 - DIAGRAMS
VOLTAGE CHECK POINTS
[1] Check voltage from AC Adapter
Normal voltage : 19.5V
[4] Check voltage for Digital circuit
Normal voltage :12V
[2] Check voltage for standby power
Normal voltage :5.8V
[3] Check voltage for IC9000 standby power
Normal voltage :3.3V
SAL-1001 (A SIDE VIEW)
