FMP-X10 30
SECTION 4 - DIAGRAMS
CHECKING THE STANDBY POWER (5.8V) VOLTAGE
Check point (Around IC9704)
Check Voltage (5.8V)
19.5V
(From AC Adapter)
5.8V
(for Standby circuit)
IC9704 & L9702
