Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 58 —
R484 1-247-807-31 CARBON 100 5% 1/4W
R485 1-247-807-31 CARBON 100 5% 1/4W
R486 1-249-437-11 CARBON 47K 5% 1/4W
R487 1-249-437-11 CARBON 47K 5% 1/4W
R488 1-249-432-11 CARBON 18K 5% 1/4W
R489 1-249-437-11 CARBON 47K 5% 1/4W
R490 1-249-437-11 CARBON 47K 5% 1/4W
R491 1-249-413-11 CARBON 470 5% 1/4W F
R493 1-249-413-11 CARBON 470 5% 1/4W F
R494 1-249-413-11 CARBON 470 5% 1/4W F
R521 1-249-437-11 CARBON 47K 5% 1/4W
R522 1-249-441-11 CARBON 100K 5% 1/4W
R523 1-249-417-11 CARBON 1K 5% 1/4W F
R524 1-249-429-11 CARBON 10K 5% 1/4W
R525 1-247-887-00 CARBON 220K 5% 1/4W
R526 1-249-442-11 CARBON 510 5% 1/4W
R527 1-247-858-11 CARBON 13K 5% 1/4W
R528 1-249-421-11 CARBON 2.2K 5% 1/4W F
R529 1-249-429-11 CARBON 10K 5% 1/4W
R542 1-249-428-11 CARBON 8.2K 5% 1/4W F
R543 1-247-887-00 CARBON 220K 5% 1/4W
R544 1-249-437-11 CARBON 47K 5% 1/4W
R545 1-249-431-11 CARBON 15K 5% 1/4W
R546 1-249-435-11 CARBON 33K 5% 1/4W
R548 1-249-435-11 CARBON 33K 5% 1/4W
R549 1-249-421-11 CARBON 2.2K 5% 1/4W F
R551 1-249-426-11 CARBON 5.6K 5% 1/4W
R560 1-247-887-00 CARBON 220K 5% 1/4W
R921 1-247-843-11 CARBON 3.3K 5% 1/4W
R925 1-247-843-11 CARBON 3.3K 5% 1/4W
************************************************************
* A-4403-559-A RDS BOARD, COMPLETE (AEP,G,UK)
********************
< CAPACITOR >
C601 1-162-291-31 CERAMIC 560PF 10% 50V
C602 1-162-306-11 CERAMIC 0.01uF 20% 16V
C603 1-162-288-31 CERAMIC 330PF 10% 50V
C604 1-126-961-11 ELECT 2.2uF 20% 50V
C605 1-126-964-11 ELECT 10uF 20% 50V
C606 1-162-291-31 CERAMIC 560PF 10% 50V
C607 1-126-964-11 ELECT 10uF 20% 50V
C608 1-164-159-11 CERAMIC 0.1uF 50V
C609 1-126-967-11 ELECT 47uF 20% 16V
C610 1-102-518-11 CERAMIC 33PF 5% 50V
C611 1-102-518-11 CERAMIC 33PF 5% 50V
C612 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN601 1-779-939-11 CONNECTOR, BOARD TO BOARD 7P
< DIODE >
D601 8-719-911-19 DIODE 1SS119
< IC >
IC601 8-759-450-86 IC BU1922
IC602 8-759-634-51 IC M5218AP
< COIL >
L601 1-410-977-11 INDUCTOR 100uH
< RESISTOR >
R601 1-249-401-11 CARBON 47 5% 1/4W F
R602 1-249-441-11 CARBON 100K 5% 1/4W
R603 1-249-441-11 CARBON 100K 5% 1/4W
R604 1-249-426-11 CARBON 5.6K 5% 1/4W
R605 1-249-429-11 CARBON 10K 5% 1/4W
R606 1-249-405-11 CARBON 100 5% 1/4W F
R607 1-249-417-11 CARBON 1K 5% 1/4W F
< VIBRATOR >
X601 1-579-900-21 VIBRATOR, CRYSTAL 4.332MHz
************************************************************
* 1-667-822-11 RELAY BOARD
************
< CAPACITOR >
C820 1-126-794-11 ELECT 4.7uF 20% 50V
C821 1-126-177-11 ELECT 100uF 20% 10V
C822 1-164-159-11 CERAMIC 0.1uF 50V
C823 1-164-159-11 CERAMIC 0.1uF 50V
C824 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN812 1-569-502-11 PIN, CONNECTOR 7P
* CN813 1-691-174-11 CONNECTOR (BOARD TO BOARD) 4P
CN814 1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D820 8-719-933-50 DIODE HZS7C2L
D821 8-719-933-39 DIODE HZS6C1L
D822 8-719-911-19 DIODE 1SS119
D823 8-719-911-19 DIODE 1SS119
< TRANSISTOR >
Q820 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q821 8-729-620-05 TRANSISTOR 2SC2603-EF
Q822 8-729-620-05 TRANSISTOR 2SC2603-EF
Q823 8-729-620-05 TRANSISTOR 2SC2603-EF
Q824 8-729-140-96 TRANSISTOR 2SD774-34
< RESISTOR >
R820 1-249-417-11 CARBON 1K 5% 1/4W F
R821 1-249-441-11 CARBON 100K 5% 1/4W
R822 1-249-429-11 CARBON 10K 5% 1/4W
R823 1-249-441-11 CARBON 100K 5% 1/4W
R824 1-249-413-11 CARBON 470 5% 1/4W F
! R825 1-212-966-00 FUSIBLE 22 5% 1/2W F
R826 1-249-441-11 CARBON 100K 5% 1/4W
R827 1-249-441-11 CARBON 100K 5% 1/4W
R828 1-249-429-11 CARBON 10K 5% 1/4W
************************************************************
PRE RDS RELAY
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
To Next Page
