Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 59 —
* 1-653-378-51 SENSOR BOARD
*************
< DIODE >
D801 8-719-045-75 DIODE CL-200IR-X-TU
D803 8-719-045-75 DIODE CL-200IR-X-TU
D804 8-719-045-75 DIODE CL-200IR-X-TU
< RESISTOR >
R801 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R803 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R804 1-216-049-91 METAL GLAZE 1K 5% 1/10W
< SWITCH >
S802 1-692-441-11 SWITCH, MICROPHONE
************************************************************
* 1-667-386-11 SP TM BOARD
************
< CAPACITOR >
C806 1-164-159-11 CERAMIC 0.1uF 50V
(AEP,G,UK)
C856 1-164-159-11 CERAMIC 0.1uF 50V
(AEP,G,UK)
< CONNECTOR >
CN803 1-691-161-11 PIN, CONNECTOR 4P
< COIL >
L801 1-420-872-00 COIL, AIR-CORE (AEP,G,UK)
L851 1-420-872-00 COIL, AIR-CORE (AEP,G,UK)
< RESISTOR >
R805 1-260-076-11 CARBON 10 5% 1/2W
(AEP,G,UK)
R806 1-249-393-11 CARBON 10 5% 1/4W F
(AEP,G,UK)
R855 1-260-076-11 CARBON 10 5% 1/2W
(AEP,G,UK)
R856 1-249-393-11 CARBON 10 5% 1/4W F
(AEP,G,UK)
< TERMINAL >
TM801 1-537-238-31 TERMINAL BOARD
(SPEAKER IMPEDANCE USE 4-16 (L+,L-,R+,R-))
************************************************************
* 1-667-385-11 SWITCH BOARD
*************
< CONNECTOR >
CN751 1-766-928-11 CONNECTOR, BOARD TO BOARD 8P
< DIODE >
D751 8-719-056-12 DIODE SML79420C-TP4 (PLAY/PAUSE)
< RESISTOR >
R750 1-249-427-11 CARBON 6.8K 5% 1/4W F
R751 1-249-429-11 CARBON 10K 5% 1/4W
R752 1-247-858-11 CARBON 13K 5% 1/4W
R753 1-249-433-11 CARBON 22K 5% 1/4W
R762 1-249-425-11 CARBON 4.7K 5% 1/4W F
R763 1-249-427-11 CARBON 6.8K 5% 1/4W F
R764 1-249-429-11 CARBON 10K 5% 1/4W
R765 1-247-858-11 CARBON 13K 5% 1/4W
< SWITCH >
S751 1-762-875-21 SWITCH, KEYBOARD (DBFB)
S752 1-762-875-21 SWITCH, KEYBOARD (VOL–)
S753 1-762-875-21 SWITCH, KEYBOARD (VOL+)
S754 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S762 1-762-875-21 SWITCH, KEYBOARD (BAND)
S763 1-762-875-21 SWITCH, KEYBOARD (TUNE–/ 0 / =)
S764 1-762-875-21 SWITCH, KEYBOARD (TUNE+/ ) / + )
S765 1-762-875-21 SWITCH, KEYBOARD (flPLAY/PAUSE)
S766 1-762-875-21 SWITCH, KEYBOARD (p)
************************************************************
* 1-667-384-11 TRANS BOARD
************
1-533-293-11 FUSE HOLDER
< CONNECTOR >
* CN902 1-573-047-11 PIN, CONNECTOR (PC BOARD) 2P
CN905 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
< FUSE >
! F901 1-532-388-51 FUSE TIME, LAG 2A/250V
************************************************************
* 1-667-382-11 VOLSEL BOARD (MY, SP, HK, JE)
*************
1-533-293-11 FUSE HOLDER
< CONNECTOR >
* CN920 1-564-507-11 PLUG, CONNECTOR 4P
< FUSE >
! F902 1-532-505-51 FUSE TIME, LAG 5A/250V
! F903 1-532-505-51 FUSE TIME, LAG 5A/250V
< SWITCH >
! S901 1-554-752-11 SELECTOR, POWER VOLTAGE
(VOLTAGE SELECTOR)
************************************************************
SP TMSENSOR SWITCH TRANS VOLSEL
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
