Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 60 —
HCD-101
Sony Corporation
Home A&V Products Company
97I1675-1
Printed in Japan © 1997.9
Published by General Engineering Dept.
(Shibaura)
9-920-988-11
MISCELLANEOUS
**************
13 1-782-805-11 WIRE (FLAT TYPE) (5 CORE)
14 1-782-781-11 WIRE (FLAT TYPE) (27 CORE)
54 1-782-780-11 WIRE (FLAT TYPE) (21 CORE)
58 1-698-997-11 FAN, DC
! 65 1-776-060-11 CORD, POWER (EXCEPT UK)
! 65 1-776-061-21 CORD, POWER (UK)
! 72 1-569-008-11 ADAPTOR, CONVERSION 2P (SP,MY)
! 73 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
! 152 8-848-283-11 OPTICAL PICK-UP KSS-313A
M101 X-3367-484-2 MOTOR (SP) ASSY (SPINDLE)
M102 A-3252-585-A MOTOR (SL) ASSY (SLED)
M103 A-3252-580-A MOTOR (L) ASSY (LOADING)
! T901 1-431-559-11 TRANSFORMER, POWER (AEP,G,UK)
!T901 1-431-560-11 TRANSFORMER, POWER (SP,MY,HK,JE)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-871-09 SCREW +BVTT 3X6 (S)
#3 7-685-862-09 SCREW +BVTT 2.6X6 (S)
#4 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#5 7-685-871-01 SCREW +BVTT 3X6 (S)
#6 7-621-772-60 SCREW +B 2X12
#7 7-627-852-17 +P 1.7X4
#8 7-627-553-37 SCREW , PRECISION +P2X3
#9 7-627-553-67 SCREW , PRECISION +P2X5
#10 7-685-851-01 SCREW +BVTT 2X4 (S)
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
