Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
107
HCD-AZ2D/AZ5D
R758 1-216-864-11 SHORT CHIP 0
R759 1-216-809-11 METAL CHIP 100 5% 1/10W
R760 1-216-864-11 SHORT CHIP 0
R762 1-216-864-11 SHORT CHIP 0
R763 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R764 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R765 1-216-864-11 SHORT CHIP 0
R768 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R769 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R770 1-216-790-11 METAL CHIP 2.7 5% 1/10W
R771 1-216-790-11 METAL CHIP 2.7 5% 1/10W
R772 1-216-845-11 METAL CHIP 100K 5% 1/10W
R773 1-216-845-11 METAL CHIP 100K 5% 1/10W
R774 1-216-845-11 METAL CHIP 100K 5% 1/10W
R775 1-216-222-00 RES-CHIP 10K 5% 1/8W
R783 1-216-821-11 METAL CHIP 1K 5% 1/10W
R785 1-216-222-00 RES-CHIP 10K 5% 1/8W
R786 1-216-857-11 METAL CHIP 1M 5% 1/10W
R787 1-216-809-11 METAL CHIP 100 5% 1/10W
R788 1-216-841-11 METAL CHIP 47K 5% 1/10W
R789 1-216-841-11 METAL CHIP 47K 5% 1/10W
R790 1-216-222-00 RES-CHIP 10K 5% 1/8W
R791 1-216-809-11 METAL CHIP 100 5% 1/10W
R792 1-216-837-11 METAL CHIP 22K 5% 1/10W
R793 1-216-837-11 METAL CHIP 22K 5% 1/10W
R794 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R795 1-216-837-11 METAL CHIP 22K 5% 1/10W
R796 1-216-222-00 RES-CHIP 10K 5% 1/8W
< VIBRATOR >
X501 1-795-843-11 VIBRATOR, CRYSTA (12.288MHz)
X502 1-795-660-21 QUARTZ CRYSTAL UNIT (49.152MHz)
*************************************************************
SP OUT BOARD
*************
< CAPACITOR >
C1113 1-131-992-11 CERAMIC CHIP 100000PF 35V
(AZ2D: KR)
C1114 1-131-992-11 CERAMIC CHIP 100000PF 35V
(AZ2D: KR)
C1115 1-131-992-11 CERAMIC CHIP 100000PF 35V
(AZ2D: KR)
C1116 1-131-992-11 CERAMIC CHIP 100000PF 35V
(AZ2D: KR)
C1117 1-131-992-11 CERAMIC CHIP 100000PF 35V
(AZ2D: KR)
C1118 1-131-992-11 CERAMIC CHIP 100000PF 35V
(AZ2D: KR)
C1119 1-131-992-11 CERAMIC CHIP 100000PF 35V
(AZ2D: KR)
C1120 1-131-992-11 CERAMIC CHIP 100000PF 35V
(AZ2D: KR)
C1137 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1138 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1139 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1140 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1141 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AZ5D)
C1142 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AZ5D)
C1143 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AZ5D)
C1144 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AZ5D)
C1145 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AZ5D)
C1146 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AZ5D)
C1147 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AZ5D)
C1148 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AZ5D)
< CONNECTOR >
CN1100 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CN1101 1-691-766-11 PLUG (MICRO CONNECTOR) 4P (AZ5D)
CN1102 1-691-768-11 PLUG (MICRO CONNECTOR) 6P (AZ5D)
< COIL >
L1101 1-420-872-52 COIL, AIR-CORE (AZ2D: KR)
L1102 1-420-872-52 COIL, AIR-CORE (AZ2D: KR)
L1103 1-420-872-52 COIL, AIR-CORE (AZ2D: KR)
L1104 1-420-872-52 COIL, AIR-CORE (AZ2D: KR)
< RESISTOR >
R1101 1-245-711-31 CARBON 10 5% 1/2W
(AZ2D: KR)
R1102 1-245-711-31 CARBON 10 5% 1/2W
(AZ2D: KR)
R1103 1-245-711-31 CARBON 10 5% 1/2W
(AZ2D: KR)
R1104 1-245-711-31 CARBON 10 5% 1/2W
(AZ2D: KR)
R1113 1-245-711-31 CARBON 10 5% 1/2W
(AZ2D: KR)
R1114 1-245-711-31 CARBON 10 5% 1/2W
(AZ2D: KR)
R1115 1-245-711-31 CARBON 10 5% 1/2W
(AZ2D: KR)
R1116 1-245-711-31 CARBON 10 5% 1/2W
(AZ2D: KR)
< TERMINAL >
TM1100 1-780-224-11 TERMINAL BOARD (SP) (2P) (AZ5D)
(SPEAKER FRONT L/R)
TM1100 1-780-226-11 TERMINAL BOARD (SP) (2P) (AZ2D)
(SPEAKER FRONT L/R)
TM1101 1-780-225-11 TERMINAL BOARD (SP) (4P) (AZ5D)
(SPEAKER SURR L/R, S.WOOFER, CENTER)
*************************************************************
VIDEO BOARD
************
< CAPACITOR/JUMPER RESISTOR >
C1201 1-126-960-11 ELECT 1uF 20% 50V
C1202 1-126-960-11 ELECT 1uF 20% 50V
C1203 1-126-960-11 ELECT 1uF 20% 50V
C1204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1205 1-126-965-11 ELECT 22uF 20% 50V
S-MASTER SP OUT VIDEO
