HCD-AZ2D/AZ5D
8-2. FRONT PANEL SECTION
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
51
60
(including touch sensor (TS1))
52
61
53
62
54
63
55
64
56
65
57
66
58
67
59
59
59
59
59
59
59
59
59
59
59
59
59
59
59
59
59
59
68
69
not supplied
not supplied
not supplied
not
supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
(touch sensor (TS1))
not supplied
(touch sensor (TS1
included in
60
)
not supplied
(KEY board)
not supplied
(SIRCS board)
not supplied
(EJECTboard)
#2
#1
not supplied
not supplied
not supplied
not supplied
51 2-349-646-01 PLATE (TC), INDICATION
52 2-349-645-01 PANEL (LID)
53 2-349-647-01 LID (TC-B)
54 4-238-631-01 TAPE SPRING
55 2-349-654-01 LID (MIC)
56 4-231-841-01 SPRING (HEART CAM-B)
57 4-231-825-01 CAM (B), HEART
58 4-224-104-41 DAMPER
59 3-087-053-01 +BVTP 2.6 (3CR)
60 X-2025-505-1 FRONT PANEL ASSY (D)
(AZ5D: E3, E12, E15, EA, SP, MY, AUS)
60 X-2048-633-1 FRONT PANEL ASSY (2D) (AZ2D)
60 X-2055-470-1 FRONT PANEL ASSY (AZ5D: TH)
60 X-2059-332-1 FRONT PANEL ASSY (AZ5D: E2)
61 1-769-977-11 WIRE (FLAT TYPE) (13 CORE)
62 1-828-320-11 WIRE (FLAT TYPE) (11 CORE)
63 1-469-829-11 CORE, FERRITE
64 A-1091-269-A FL BOARD, COMPLETE (EXCEPT AZ5D: TH)
64 A-1114-866-A FL BOARD, COMPLETE (AZ5D: TH)
65 1-828-936-11 WIRE (FLAT TYPE) (5 CORE)
66 1-790-378-11 WIRE (FLAT TYPE) (8 CORE)
67 1-797-175-11 DECK, MECH (CMAL1Z254A) (DECK-B)
68 A-1091-273-A MIC BOARD, COMPLETE (EXCEPT AZ5D: TH)
68 A-1114-870-A MIC BOARD, COMPLETE (AZ5D: TH)
69 4-245-464-02 DAMPER
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#2 7-685-853-04 SCREW +BVTT 2X6 (S)
