12
HCD-AZ2D/AZ5D
Note: Follow the disassembly procedure in the numerical order given.
3-2. SIDE PANEL (A)/(B)
2
three screws
(BVTP 3
×
8)
7
three screws
(BVTP 3
×
8)
3
4
7
8
1
three flat head screws
6
three flat head screws
5
side panel (A)
9
side panel (B)
3-3. FRONT PANEL SECTION
1
two screws
(BVTP 3
×
8)
3
two claws
4
1
two screws
(BVTP 3
×
8)
2
three ground wires
1
screw
(BVTP 3
×
8)
8
wire (flat type) (8 core)
(CN304)
9
connector
(CN302)
q;
front panel section
9
connector
(CN1050)
7
wire (flat type) (5 core)
(CN112)
6
wire (flat type) (11 core)
(CN111)
5
wire (flat type) (13 core)
(CN113)
