21
HCD-AZ2D/AZ5D
3-18. GEAR (IDL-C)
3-17. LEVER (DISC SENSOR)/(DISC STOP)
chassis (top)
hole
Install the lever (disc stop) so that the both holes
are aligned.
hole
1
gear (cap)
3
two claws
5
two hooks
6
lever (disc stop)
lever (disc stop)
4
lever (disc sensor)
PRECAUTION DURING DISC STOP LEVER INSTALLATION
2
gear (IDL L)
4
three hooks
2
two claws
6
claw
1
gear (IDL-F)
7
gear (IDL-C)
3
gear (IDL-D)
5
lever (gear loading) assy
