HCD-AZ2D/AZ5D
TAPE MECH DECK (CMAL5Z230) (DECK-A) SERVICE POSITION
TAPE MECH DECK (CMAL1Z254A) (DECK-B) SERVICE POSITION
tape mech deck
(CMAL5Z230) (deck-A)
top panel (TC) section
tape mech deck
(CMAL1Z254A) (deck-B
)
