HCD-AZ2D/AZ5D
Pin No. Pin Name I/O Description
91 TAPE B HALF/REC I
Deck-B cassette detection signal input from the tape mechanism deck block
“L”: cassette inRecording-proof (forward and reverse direction) detection signal input
from the tape mechanism deck block “L”: recording possible
92 SPEC-IN I Destination setting input terminal (A/D input)
93 MODEL-IN I Model setting input terminal (A/D input)
94, 95 KEY_2, KEY_1 I Key input terminal (A/D input)
96 AVSS – Ground terminal (analog system)
97 TAPE A SHUT I Deck-A tape reel rotating detection signal input from the tape mechanism deck block
98 VREF I Reference voltage (+3.3V) input terminal (analog system)
99 AVCC – Power supply terminal (+3.3V) (analog system)
100 STANDBY LED O LED drive signal output of the standby indicator “H”: LED on
