Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
87
HCD-AZ2D/AZ5D
C3764 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
(AZ5D)
C3771 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C3772 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3773 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C3774 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C3781 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C3782 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3783 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C3784 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C3801 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C3802 1-117-370-11 CERAMIC CHIP 10uF 10V
C3803 1-126-209-11 ELECT CHIP 100uF 20% 4V
C3804 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3805 1-126-208-21 ELECT CHIP 47uF 20% 4V
< CONNECTOR >
CN101 1-815-763-32 CONNECTOR, FFC/FPC 24P
CN103 1-784-365-21 CONNECTOR, FFC/FPC 5P
* CN105 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN106 1-793-989-21 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 13P
* CN201 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN202 1-784-366-21 CONNECTOR, FFC/FPC 7P
CN301 1-793-989-21 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 13P
CN302 1-778-691-11 CONNECTOR, FFC/FPC 19P (AZ5D)
CN302 1-784-376-11 CONNECTOR, FFC/FPC 17P (AZ2D)
CN401 1-779-993-11 PIN, CONNECTOR (PWB) 5P
< DIODE >
D1001 8-719-058-24 DIODE RB501V-40TE-17
D3501 8-719-988-61 DIODE 1SS355TE-17
D3502 8-719-988-61 DIODE 1SS355TE-17
D3601 8-719-988-61 DIODE 1SS355TE-17 (AZ5D)
D3602 8-719-988-61 DIODE 1SS355TE-17 (AZ5D)
< FERRITE BEAD >
FB111 1-414-226-21 INDUCTOR, FERRITE BEAD
FB112 1-414-226-21 INDUCTOR, FERRITE BEAD
FB113 1-414-226-21 INDUCTOR, FERRITE BEAD
FB114 1-414-226-21 INDUCTOR, FERRITE BEAD
FB115 1-414-226-21 INDUCTOR, FERRITE BEAD
FB401 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB402 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB403 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB404 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB405 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB406 1-469-324-21 FERRITE, EMI (SMD) (2012)
< FILTER >
FL101 1-234-177-21 FILTER, CHIP EMI
FL104 1-234-177-21 FILTER, CHIP EMI
FL105 1-234-177-21 FILTER, CHIP EMI
FL106 1-234-177-21 FILTER, CHIP EMI
FL107 1-234-177-21 FILTER, CHIP EMI
FL108 1-234-177-21 FILTER, CHIP EMI
FL401 1-234-177-21 FILTER, CHIP EMI
FL402 1-233-893-21 FILTER, CHIP EMI
FL403 1-234-177-21 FILTER, CHIP EMI
< IC >
IC101 6-805-728-01 IC S29JL032H70-SBS1-0503UC (AZ5D: E2)
IC101 6-805-729-01 IC S29JL032H70-SBS1-0503CE
(AZ5D: E3, E12, E15, EA, AUS)
IC101 6-805-730-01 IC S29JL032H70-SBS1-0503GA
(AZ5D: SP, MY, TH)
IC101 6-805-733-01 IC S29JL032H70-SBS2-0503UC (AZ2D: E2)
IC101 6-805-734-01 IC S29JL032H70-SBS2-0503CE
(AZ2D: E3, E12, E13, E15, EA, AUS)
IC101 6-805-735-01 IC S29JL032H70-SBS2-0503GA
(AZ2D: SP, MY, KR, PH)
IC102 6-706-727-01 IC CXD9804R
IC103 (Not supplied) IC BR24L64F-WE2
IC104 6-706-390-11 IC HY57V641620HGTP-HDR
IC105 6-702-302-01 IC TK11133CSCL-G
IC106 8-759-667-18 IC PQ018EZ01ZPH
IC107 6-702-302-01 IC TK11133CSCL-G
IC201 6-704-524-01 IC FAN8036L
IC301 6-704-222-01 IC AK4358VQ-L
IC3601 6-707-608-01 IC PCM1803DBR (AZ5D)
IC3711 8-759-359-49 IC NJM3414AV (TE2)
IC3731 8-759-359-49 IC NJM3414AV (TE2) (AZ5D)
IC3751 8-759-359-49 IC NJM3414AV (TE2) (AZ5D)
IC3771 8-759-359-49 IC NJM3414AV (TE2)
< COIL >
L3601 1-469-555-21 INDUCTOR 10uH (AZ5D)
L3602 1-469-555-21 INDUCTOR 10uH (AZ5D)
< TRANSISTOR >
Q101 6-550-008-01 FET UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q2001 8-729-025-28 FET 2SK1828
Q3801 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-833-11 METAL CHIP 10K 5% 1/10W
R104 1-216-864-11 SHORT CHIP 0
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-857-11 METAL CHIP 1M 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-801-11 METAL CHIP 22 5% 1/10W
R120 1-216-801-11 METAL CHIP 22 5% 1/10W
R121 1-216-801-11 METAL CHIP 22 5% 1/10W
R123 1-216-864-11 SHORT CHIP 0
DMB10
New part of EEPROM (IC103) on the DMB10 board can not be used.
Therefore, if the mounted DMB10 board is replaced, exchange new
EEPROM with that used before the replacement.
