Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
99
HCD-AZ2D/AZ5D
A-1091-273-A MIC BOARD, COMPLETE (EXCEPT AZ5D: TH)
A-1114-870-A MIC BOARD, COMPLETE (AZ5D: TH)
*********
< CAPACITOR >
C1053 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1060 1-115-868-11 ELECT 0.22uF 20% 50V
C1061 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1062 1-115-868-11 ELECT 0.22uF 20% 50V
C1063 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1064 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1066 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1067 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
C1068 1-115-868-11 ELECT 0.22uF 20% 50V
C1069 1-115-872-11 ELECT 2.2uF 20% 50V
C1070 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1071 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1072 1-126-791-11 ELECT 10uF 20% 35V
C1073 1-115-872-11 ELECT 2.2uF 20% 50V
C1074 1-126-176-11 ELECT 220uF 20% 10V
C1077 1-115-871-11 ELECT 1uF 20% 50V
C1078 1-115-872-11 ELECT 2.2uF 20% 50V
C1079 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C1080 1-115-871-11 ELECT 1uF 20% 50V
C1082 1-126-786-11 ELECT 47uF 20% 16V
C1083 1-126-786-11 ELECT 47uF 20% 16V
C1084 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C1085 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C1086 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1087 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1088 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1089 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C1090 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C1091 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C1092 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C1095 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1097 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1098 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN1050 1-785-334-11 PIN, CONNECTOR (LIGHT ANGLE) 8P
< DIODE >
D1061 8-719-069-54 DIODE UDZSTE-175.1B
< EARTH TERMINAL >
EP1050 1-537-738-21 TERMINAL, GROUND
EP1060 1-537-738-21 TERMINAL, GROUND
< IC >
IC1060 8-759-710-97 IC NJM4565M-D
IC1061 8-759-496-41 IC M65850FP-E1
< JACK >
J1050 1-750-032-11 JACK (DIA. 3.5) (PHONES)
J1060 1-770-226-11 JACK (LARGE TYPE) (MIC 1)
J1061 1-770-226-11 JACK (LARGE TYPE) (MIC 2)
< JUMPER RESISTOR/CAPACITOR >
JR1051 1-216-296-11 SHORT CHIP 0
JR1053 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< RESISTOR >
R1050 1-500-329-21 INDUCTOR, FERRITE BEAD
R1051 1-500-329-21 INDUCTOR, FERRITE BEAD
R1052 1-216-864-11 SHORT CHIP 0
R1060 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1061 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1062 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1063 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1064 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1065 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1066 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1067 1-216-809-11 METAL CHIP 100 5% 1/10W
R1068 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1069 1-216-847-11 METAL CHIP 150K 5% 1/10W
R1070 1-216-809-11 METAL CHIP 100 5% 1/10W
R1071 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1072 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1073 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1074 1-216-864-11 SHORT CHIP 0
R1075 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1076 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1077 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1078 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1079 1-216-813-11 METAL CHIP 220 5% 1/10W
R1080 1-216-846-11 METAL CHIP 120K 5% 1/10W
R1081 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1082 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1083 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1084 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1085 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1086 1-216-837-11 METAL CHIP 22K 5% 1/10W
< VARIABLE RESISTOR >
RV1060 1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL)
RV1061 1-223-983-11 RES, VAR, CARBON 50K (ECHO LEVEL)
*************************************************************
MS-214 BOARD
*************
< CONNECTOR >
CN001 1-815-569-11 CONNECTOR, FFC/FPC 7P
< SWITCH >
S001 1-762-951-13 SWITCH, PUSH (DISC IN/OUT)
S002 1-762-951-13 SWITCH, PUSH (CHUCKING)
S003 1-762-951-13 SWITCH, PUSH (TRIGGER)
************************************************************
