Sony HCD-BX5 - Electrical Parts Lists - Main Board Components; Main Board Filters, Diodes, and ICs

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
54
C689 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
(AED,AEP,CIS,G,UK)
C690 1-126-961-11 ELECT 2.2uF 20.00% 50V
(AED,AEP,CIS,G,UK)
C691 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(AED,AEP,CIS,G,UK)
C692 1-163-245-11 CERAMIC CHIP 56PF 5.00% 50V
(AED,AEP,CIS,G,UK)
C693 1-163-245-11 CERAMIC CHIP 56PF 5.00% 50V
(AED,AEP,CIS,G,UK)
C694 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(AED,AEP,CIS,G,UK)
C695 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(AED,AEP,CIS,G,UK)
C801 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(AED,AEP,CIS,G,UK)
C802 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(AED,AEP,CIS,G,UK)
C803 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C821 1-104-665-11 ELECT 100uF 20.00% 10V
C822 1-126-961-11 ELECT 2.2uF 20.00% 50V
C823 1-126-968-11 ELECT 100uF 20.00% 50V
C824 1-126-960-11 ELECT 1uF 20.00% 50V
C841 1-126-959-11 ELECT 0.47uF 20.00% 50V
C851 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(AED,AEP,CIS,G,UK)
C852 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(AED,AEP,CIS,G,UK)
C853 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C861 1-107-717-11 ELECT 47uF 20.00% 50V
C862 1-107-721-11 ELECT 4.7uF 20.00% 100V
C863 1-107-721-11 ELECT 4.7uF 20.00% 100V
C891 1-126-964-11 ELECT 10uF 20.00% 50V
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
C892 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
C901 1-126-944-11 ELECT 3300uF 20.00% 25V
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
C901 1-126-936-11 ELECT 3300uF 20.00% 16V
(AED,AEP,CIS,CND,G,UK,US)
C902 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C903 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C905 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C906 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C907 1-126-937-11 ELECT 4700uF 20.00% 16V
C908 1-126-942-61 ELECT 1000uF 20.00% 25V
C909 1-126-952-11 ELECT 1000uF 20.00% 35V
C911 1-126-960-11 ELECT 1uF 20.00% 50V
C912 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C921 1-126-960-11 ELECT 1uF 20.00% 50V
C922 1-126-933-11 ELECT 100uF 20.00% 16V
C931 1-126-964-11 ELECT 10uF 20.00% 50V
C932 1-126-935-11 ELECT 470uF 20.00% 16V
C951 1-126-960-11 ELECT 1uF 20.00% 50V
C952 1-104-665-11 ELECT 100uF 20.00% 10V
C961 1-126-960-11 ELECT 1uF 20.00% 50V
C962 1-126-926-11 ELECT 1000uF 20.00% 10V
< FILTER >
CF601 1-760-023-11 FILTER, CERAMIC
(CND,US,AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
CF601 1-579-185-21 FILTER, CERAMIC (AED,AEP,CIS,G,UK)
CF602 1-760-023-11 FILTER, CERAMIC
(CND,US,AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
CF602 1-579-185-21 FILTER, CERAMIC (AED,AEP,CIS,G,UK)
< CONNECTOR >
CN202 1-785-336-11 PIN, CONNECTOR(LIGHT ANGLE)10P
* CN201 1-569-913-11 S0CKET, CONNECTOR 19P
* CN301 1-568-449-11 HOUSING, CONNECTOR(PC BOARD)3P
* CN304 1-569-934-11 SOCKET, CONNECTOR 17P
CN401 1-793-766-11 CONNECTOR, BOARD TO BOARD 30P
* CN891 1-564-506-11 PLUG, CONNECTOR 3P
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
CN901 1-778-982-11 CONNECTOR, BOARD TO BOARD 13P
CN902 1-778-982-11 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D501 8-719-988-61 DIODE 1SS355TE-17
D502 8-719-988-61 DIODE 1SS355TE-17
D503 8-719-988-61 DIODE 1SS355TE-17
D504 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-988-61 DIODE 1SS355TE-17
D506 8-719-988-61 DIODE 1SS355TE-17
D508 8-719-988-61 DIODE 1SS355TE-17
D509 8-719-988-61 DIODE 1SS355TE-17
D510 8-719-988-61 DIODE 1SS355TE-17
D511 8-719-988-61 DIODE 1SS355TE-17
D601 8-719-056-83 DIODE UDZ-TE-17-6.8B
D641 8-719-914-42 DIODE DA204K-T-146
D651 8-719-988-61 DIODE 1SS355TE-17
D681 8-719-988-61 DIODE 1SS355TE-17 (AED,AEP,CIS,G,UK)
D801 8-719-988-61 DIODE 1SS355TE-17
D822 8-719-988-61 DIODE 1SS355TE-17
D841 8-719-988-61 DIODE 1SS355TE-17
D861 8-719-988-61 DIODE 1SS355TE-17
D891 8-719-988-61 DIODE 1SS355TE-17
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
D892 8-719-988-61 DIODE 1SS355TE-17
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
D901 8-719-200-82 DIODE 11ES2-TB5
D902 8-719-200-82 DIODE 11ES2-TB5
D903 8-719-200-82 DIODE 11ES2-TB5
D904 8-719-200-82 DIODE 11ES2-TB5
D906 8-719-200-82 DIODE 11ES2-TB5
D907 8-719-200-82 DIODE 11ES2-TB5
D908 8-719-200-82 DIODE 11ES2-TB5
D909 8-719-200-82 DIODE 11ES2-TB5
D910 8-719-200-82 DIODE 11ES2-TB5
D911 8-719-200-82 DIODE 11ES2-TB5
D952 8-719-988-61 DIODE 1SS355TE-17
D953 8-719-988-61 DIODE 1SS355TE-17
D957 8-719-988-61 DIODE 1SS355TE-17 (TH)
MAIN
