Sony HCD-BX5 - Electrical Parts Lists - Main Board Connectors; Main Board Ferrite Beads and Connectors

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
55
< FERRITE BEAD >
FB201 1-216-295-91 SHORT 0
FB202 1-216-295-91 SHORT 0
FB203 1-216-295-91 SHORT 0
FB204 1-216-295-91 SHORT 0
FB416 1-216-295-91 SHORT 0
FB462 1-216-295-91 SHORT 0
FB499 1-216-295-91 SHORT 0
< FRONT END >
FE601 1-693-477-11 FRONT END (3 GANGS)
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
FE602 1-693-478-11 FRONT END (FM3 GANGS)(CND,US)
FE603 1-693-496-11 FRONT END (4 GANG) (AED,AEP,CIS,G,UK)
< IC >
IC104 8-759-099-06 IC M5218AFP-TE1 (AR,AUS,E,EA,KR,MX,TH)
IC101 8-759-652-04 IC M61504FP-TP
IC102 8-759-099-06 IC M5218AFP-TE1
IC201 8-749-923-04 IC TOTX178A (OPTICAL)
IC302 8-759-143-54 IC uPC1330HA
IC303 8-759-656-83 IC NJM4580MD-TE
IC304 8-759-656-83 IC NJM4580MD-TE
IC301 8-759-652-80 IC HA12227F
IC401 8-759-652-48 IC M30622MAA-A25FP
IC501 8-759-635-63 IC M51943BSL-TP
IC601 8-759-652-00 IC BA1450
IC651 8-759-288-54 IC LC72130
IC681 8-759-099-06 IC M5218AFP-TE1 (AED,AEP,CIS,G,UK)
IC682 8-759-541-48 IC BU1924 (AED,AEP,CIS,G,UK)
IC911 8-759-039-69 IC uPC7805AHF
IC921 8-759-088-08 IC uPC7812AHF
IC931 8-759-604-86 IC M5F7807L
IC951 8-759-158-62 IC TA78057S
IC961 8-759-701-59 IC M5F7809L
< IFT >
IFT601 1-435-295-11 TRANSFORMER, IF
< JACK >
J101 1-793-987-11 JACK, PIN 2P (MD VIDEO)
< JUMPER RESISTOR >
JR1 1-216-296-91 SHORT 0
JR2 1-216-296-91 SHORT 0
JR3 1-216-296-91 SHORT 0
JR4 1-216-296-91 SHORT 0
JR6 1-216-296-91 SHORT 0
JR7 1-216-296-91 SHORT 0
JR8 1-216-295-91 SHORT 0
JR9 1-216-296-91 SHORT 0
JR10 1-216-296-91 SHORT 0
JR11 1-216-296-91 SHORT 0
JR12 1-216-296-91 SHORT 0
JR13 1-216-296-91 SHORT 0
JR14 1-216-296-91 SHORT 0
JR15 1-216-296-91 SHORT 0
JR16 1-216-295-91 SHORT 0
JR17 1-216-296-91 SHORT 0
JR18 1-216-295-91 SHORT 0
JR19 1-216-296-91 SHORT 0
JR21 1-216-295-91 SHORT 0
JR22 1-216-296-91 SHORT 0
JR23 1-216-296-91 SHORT 0
JR24 1-216-296-91 SHORT 0
JR25 1-216-296-91 SHORT 0
JR26 1-216-296-91 SHORT 0
JR27 1-216-296-91 SHORT 0
JR28 1-216-295-91 SHORT 0
JR29 1-216-296-91 SHORT 0
JR30 1-216-296-91 SHORT 0 (TH)
JR31 1-216-296-91 SHORT 0 (TH)
JR32 1-216-296-91 SHORT 0 (TH)
JR33 1-216-296-91 SHORT 0 (TH)
JR34 1-216-295-91 SHORT 0 (TH)
JR35 1-216-296-91 SHORT 0 (TH)
JR36 1-216-295-91 SHORT 0 (TH)
JR37 1-216-296-91 SHORT 0 (TH)
JR38 1-216-296-91 SHORT 0 (TH)
JR39 1-216-296-91 SHORT 0 (TH)
JR41 1-216-296-91 SHORT 0 (TH)
JR42 1-216-295-91 SHORT 0 (TH)
JR43 1-216-296-91 SHORT 0 (TH)
JR44 1-216-296-91 SHORT 0 (TH)
JR45 1-216-296-91 SHORT 0 (TH)
JR50 1-216-296-91 SHORT 0 (AED,AEP,CIS,CND,G,UK,US)
JR51 1-216-296-91 SHORT 0 (TH)
JR609 1-216-295-91 SHORT 0(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
JR601 1-216-296-91 SHORT 0 (EXCEPT US,CND)
JR602 1-216-295-91 SHORT 0
JR603 1-216-296-91 SHORT 0
JR604 1-216-296-91 SHORT 0
JR605 1-216-296-91 SHORT 0
JR606 1-216-296-91 SHORT 0
JR607 1-216-295-91 SHORT 0
JR608 1-216-296-91 SHORT 0
JR612 1-216-295-91 SHORT 0 (CND,US)
JR611 1-216-296-91 SHORT 0
JR614 1-216-295-91 SHORT 0 (AED,AEP,CIS,G,UK)
JR615 1-216-295-91 SHORT 0
JR616 1-216-295-91 SHORT 0
JR619 1-216-295-91 SHORT 0
JR632 1-216-295-91 SHORT 0 (CND,US)
JR634 1-216-295-91 SHORT 0
JR636 1-216-295-91 SHORT 0 (AED,AEP,CIS,G,UK)
JR640 1-216-295-91 SHORT 0
(CND,US,AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
JR641 1-216-295-91 SHORT 0 (AED,AEP,CIS,G,UK)
JR907 1-216-295-91 SHORT 0 (AED,AEP,CIS,CND,G,UK,US)
MAIN
