Sony HCD-BX5 - Electrical Parts Lists - Main Board Resistors (Cont.); Main Board Resistors (Part 2)

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
58
R429 1-216-025-91 RES-CHIP 100 5% 1/10W
R430 1-216-025-91 RES-CHIP 100 5% 1/10W
R432 1-216-025-91 RES-CHIP 100 5% 1/10W
R433 1-216-025-91 RES-CHIP 100 5% 1/10W
R435 1-216-033-00 METAL CHIP 220 5% 1/10W
R437 1-216-033-00 METAL CHIP 220 5% 1/10W
R440 1-216-295-91 SHORT 0
R441 1-216-295-91 SHORT 0
R442 1-216-295-91 SHORT 0
R443 1-216-295-91 SHORT 0 (EXCEPT EA,MX)
R444 1-216-295-91 SHORT 0 (EXCEPT EA,MX)
R445 1-216-295-91 SHORT 0 (EXCEPT EA,MX)
R446 1-216-295-91 SHORT 0 (EXCEPT EA,MX)
R447 1-216-295-91 SHORT 0 (EXCEPT EA,MX)
R448 1-216-295-91 SHORT 0 (EXCEPT EA,MX)
R449 1-216-295-91 SHORT 0 (EXCEPT EA,MX)
R467 1-216-295-91 SHORT 0 (EXCEPT EA,MX)
R468 1-216-295-91 SHORT 0 (EXCEPT EA,MX)
R469 1-216-295-91 SHORT 0 (EXCEPT EA,MX)
R481 1-216-025-91 RES-CHIP 100 5% 1/10W
(AED,AEP,CIS,CND,G,UK,US)
R483 1-216-073-00 METAL CHIP 10K 5% 1/10W
R484 1-216-073-00 METAL CHIP 10K 5% 1/10W
R490 1-216-174-00 RES-CHIP 100 5% 1/8W
R491 1-216-174-00 RES-CHIP 100 5% 1/8W
R493 1-216-174-00 RES-CHIP 100 5% 1/8W
R494 1-216-295-91 SHORT 0
R495 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R496 1-216-089-91 RES-CHIP 47K 5% 1/10W
R497 1-216-295-91 SHORT 0 (MY,SP,TW)
R497 1-216-073-00 METAL CHIP 10K 5% 1/10W
(EA)
R497 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
(AUS,KR,TH)
R497 1-216-081-00 METAL CHIP 22K 5% 1/10W
(AR,E,MX)
R497 1-216-089-91 RES-CHIP 47K 5% 1/10W
(AED,AEP,CIS,CND,G,UK,US)
R498 1-216-089-91 RES-CHIP 47K 5% 1/10W
(AR,AUS,E,EA,KR,MX,TH)
R498 1-216-073-00 METAL CHIP 10K 5% 1/10W
(CND,US)
R498 1-216-085-00 METAL CHIP 33K 5% 1/10W
(AED,AEP,CIS,G,UK)
R499 1-216-025-91 RES-CHIP 100 5% 1/10W
R501 1-216-073-00 METAL CHIP 10K 5% 1/10W
R502 1-216-089-91 RES-CHIP 47K 5% 1/10W
R503 1-216-089-91 RES-CHIP 47K 5% 1/10W
R504 1-216-025-91 RES-CHIP 100 5% 1/10W
R505 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R506 1-216-041-00 METAL CHIP 470 5% 1/10W
R508 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R509 1-216-081-00 METAL CHIP 22K 5% 1/10W
R510 1-216-097-91 RES-CHIP 100K 5% 1/10W
R523 1-216-073-00 METAL CHIP 10K 5% 1/10W
R524 1-216-073-00 METAL CHIP 10K 5% 1/10W
R546 1-216-073-00 METAL CHIP 10K 5% 1/10W
R547 1-216-073-00 METAL CHIP 10K 5% 1/10W
R548 1-216-073-00 METAL CHIP 10K 5% 1/10W
R566 1-216-073-00 METAL CHIP 10K 5% 1/10W
R601 1-216-295-91 SHORT 0 (EXCEPT US,CND)
R602 1-216-029-00 METAL CHIP 150 5% 1/10W
R603 1-216-037-00 METAL CHIP 330 5% 1/10W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R603 1-216-045-00 METAL CHIP 680 5% 1/10W
(AED,AEP,CIS,CND,G,UK,US)
R604 1-216-017-91 RES-CHIP 47 5% 1/10W
R605 1-216-045-00 METAL CHIP 680 5% 1/10W
R606 1-216-037-00 METAL CHIP 330 5% 1/10W
R607 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R608 1-216-017-91 RES-CHIP 47 5% 1/10W
R609 1-216-295-91 SHORT 0 (CND,US)
R610 1-216-045-00 METAL CHIP 680 5% 1/10W
R611 1-216-182-00 RES-CHIP 220 5% 1/8W
R612 1-216-214-00 RES-CHIP 4.7K 5% 1/8W
R613 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R614 1-216-041-00 METAL CHIP 470 5% 1/10W
(E)
R614 1-216-039-00 METAL CHIP 390 5% 1/10W
(CND,US,AR,AUS,EA,KR,MX,MY,SP,TH,TW)
R614 1-216-035-00 METAL CHIP 270 5% 1/10W
(AED,AEP,CIS,G,UK)
R615 1-216-049-91 RES-CHIP 1K 5% 1/10W
R616 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R617 1-216-041-00 METAL CHIP 470 5% 1/10W
(E)
R617 1-216-039-00 METAL CHIP 390 5% 1/10W
(CND,US,AR,AUS,EA,KR,MX,MY,SP,TH,TW)
R617 1-216-035-00 METAL CHIP 270 5% 1/10W
(AED,AEP,CIS,G,UK)
R618 1-216-049-91 RES-CHIP 1K 5% 1/10W
R619 1-216-025-91 RES-CHIP 100 5% 1/10W
R620 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R621 1-216-075-00 METAL CHIP 12K 5% 1/10W
R622 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R623 1-216-073-00 METAL CHIP 10K 5% 1/10W
R624 1-216-073-00 METAL CHIP 10K 5% 1/10W
R625 1-216-073-00 METAL CHIP 10K 5% 1/10W
R641 1-216-097-91 RES-CHIP 100K 5% 1/10W
R642 1-216-073-00 METAL CHIP 10K 5% 1/10W
R655 1-216-073-00 METAL CHIP 10K 5% 1/10W
R656 1-216-222-00 RES-CHIP 10K 5% 1/8W
R658 1-216-174-00 RES-CHIP 100 5% 1/8W
R659 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R660 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R661 1-216-025-91 RES-CHIP 100 5% 1/10W
R662 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R663 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R664 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R665 1-216-025-91 RES-CHIP 100 5% 1/10W
R666 1-216-073-00 METAL CHIP 10K 5% 1/10W
R667 1-216-222-00 RES-CHIP 10K 5% 1/8W
R668 1-216-049-91 RES-CHIP 1K 5% 1/10W
R669 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R681 1-216-025-91 RES-CHIP 100 5% 1/10W
(AED,AEP,CIS,G,UK)
R682 1-216-073-00 METAL CHIP 10K 5% 1/10W
(AED,AEP,CIS,G,UK)
MAIN
