Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
59
R683 1-216-097-91 RES-CHIP 100K 5% 1/10W
(AED,AEP,CIS,G,UK)
R684 1-216-097-91 RES-CHIP 100K 5% 1/10W
(AED,AEP,CIS,G,UK)
R685 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
(AED,AEP,CIS,G,UK)
R686 1-216-166-00 RES-CHIP 47 5% 1/8W
(AED,AEP,CIS,G,UK)
R688 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
(AED,AEP,CIS,G,UK)
R689 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
(AED,AEP,CIS,G,UK)
R801 1-260-304-51 CARBON 10 5% 1/2W
(AED,AEP,CIS,G,UK)
R802 1-260-304-51 CARBON 10 5% 1/2W
(AED,AEP,CIS,G,UK)
R804 1-216-089-91 RES-CHIP 47K 5% 1/10W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R821 1-216-089-91 RES-CHIP 47K 5% 1/10W
R822 1-216-091-00 METAL CHIP 56K 5% 1/10W
R823 1-216-073-00 METAL CHIP 10K 5% 1/10W
R824 1-216-073-00 METAL CHIP 10K 5% 1/10W
R825 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R826 1-216-085-00 METAL CHIP 33K 5% 1/10W
R827 1-216-081-00 METAL CHIP 22K 5% 1/10W
R829 1-216-081-00 METAL CHIP 22K 5% 1/10W
R831 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R841 1-216-081-00 METAL CHIP 22K 5% 1/10W
R842 1-216-081-00 METAL CHIP 22K 5% 1/10W
R843 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R844 1-216-097-91 RES-CHIP 100K 5% 1/10W
R845 1-216-121-91 RES-CHIP 1M 5% 1/10W
R851 1-260-304-51 CARBON 10 5% 1/2W
(AED,AEP,CIS,G,UK)
R852 1-260-304-51 CARBON 10 5% 1/2W
(AED,AEP,CIS,G,UK)
R854 1-216-089-91 RES-CHIP 47K 5% 1/10W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R861 1-216-049-91 RES-CHIP 1K 5% 1/10W
R862 1-216-073-00 METAL CHIP 10K 5% 1/10W
R863 1-216-089-91 RES-CHIP 47K 5% 1/10W
R864 1-216-049-91 RES-CHIP 1K 5% 1/10W
R865 1-216-049-91 RES-CHIP 1K 5% 1/10W
R866 1-216-019-00 METAL CHIP 56 5% 1/10W
R868 1-215-891-11 METAL OXIDE 680 5% 2W
R869 1-215-891-11 METAL OXIDE 680 5% 2W
R891 1-216-296-91 SHORT 0 (TH)
R891 1-216-222-00 RES-CHIP 10K 5% 1/8W
(AR,AUS,E,EA,KR,MX,MY,SP,TW)
R892 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R893 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R912 1-216-222-00 RES-CHIP 10K 5% 1/8W
0 R916 1-219-120-51 FUSIBLE 0.15 5% 1/4W
R923 1-216-295-91 SHORT 0 (TH)
R924 1-216-295-91 SHORT 0 (TH)
R928 1-216-295-91 SHORT 0 (TH)
R966 1-216-019-00 METAL CHIP 56 5% 1/10W
< COMPOSITION CIRCUIT BLOCK >
RB641 1-234-457-11 ENCAPSULATED COMPONENT
< VARIABLE RESISTOR >
RV301 1-241-764-11 RES, ADJ, CARBON 10K
RV302 1-241-762-11 RES, ADJ, CARBON 2.2K
RV303 1-241-762-11 RES, ADJ, CARBON 2.2K
RV304 1-241-768-11 RES, ADJ, CARBON 220K
RV351 1-241-764-11 RES, ADJ, CARBON 10K
RV352 1-241-762-11 RES, ADJ, CARBON 2.2K
RV353 1-241-762-11 RES, ADJ, CARBON 2.2K
RV354 1-241-768-11 RES, ADJ, CARBON 220K
RV611 1-238-601-11 RES, ADJ, CARBON 22K
< RELAY >
RY801 1-755-373-11 RELAY (EXCEPT MY,SP,TW)
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
T601 1-435-195-11 TRANSFORMER, DISCRIMINATOR
T602 1-234-477-11 ENCAPSULATED COMPONENT
(AED,AEP,CIS,G,UK)
< TERMINAL >
TM601 1-694-555-11 TERMINAL BOARD (4P) (FM/AM)
(CND,US,AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
TM601 1-694-556-21 TERMINAL BOARD (ANT.PAL) (FM/AM)
(AED,AEP,CIS,G,UK)
TM801 1-694-635-11 TERMINAL BOARD (4P) (SPEAKER)
< VIBRATOR >
X401 1-567-098-41 VIBRATOR, CRYSTAL 32.768KHz
X402 1-781-107-21 VIBRATOR, SERAMIC 16MHz
X651 1-760-549-31 VIBRATOR, CRYSTAL 4.5MHz
< VIBRATOR >
XT681 1-579-900-21 VIBRATOR, CRYSTAL (AED,AEP,CIS,G,UK)
**************************************************************
1-675-910-11 MOTOR BOARD
************
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
CN721 1-770-516-31 CONNECTOR, FFC 8P
CN722 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE)4P
< SWITCH >
S701 1-771-822-11 SWITCH, LEVER (SLIDE)
**************************************************************
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
MAIN MOTOR
To Next Page
