Sony HCD-BX5 - Electrical Parts Lists - Panel, CD Switch, Power Amp; Parts for Panel, CD Switch, Power Amp

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
63
S620 1-762-875-21 SWITCH, KEYBOARD (PAUSE)
S621 1-762-875-21 SWITCH, KEYBOARD (-AMS)
S623 1-762-875-21 SWITCH, KEYBOARD (LEFT)
S624 1-762-875-21 SWITCH, KEYBOARD (RIGHT)
S625 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B)
S626 1-762-875-21 SWITCH, KEYBOARD (STOP)
S627 1-762-875-21 SWITCH, KEYBOARD (CD)
S628 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S629 1-762-875-21 SWITCH, KEYBOARD (PLAY)
S630 1-762-875-21 SWITCH, KEYBOARD (MD(VIDEO))
S631 1-762-875-21 SWITCH, KEYBOARD (REV)
S632 1-762-875-21 SWITCH, KEYBOARD (SURROUND)
S633 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
S634 1-762-875-21 SWITCH, KEYBOARD (REPEAT)
S635 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE)
S636 1-762-875-21 SWITCH, KEYBOARD (EDIT)
S637 1-762-875-21 SWITCH, KEYBOARD (POWER)
S638 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S639 1-762-875-21 SWITCH, KEYBOARD (EQ EDIT)
S640 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM)
S641 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
< VIBRATOR >
X601 1-579-352-11 VIBRATOR, CERAMIC 12.5MHz
**************************************************************
A-4428-077-A CD SWITCH BOARD, COMPLETE
**************************
< DIODE >
D630 8-719-056-13 DIODE SML79423C-TP15
D631 8-719-056-13 DIODE SML79423C-TP15
D632 8-719-056-13 DIODE SML79423C-TP15
< TRANSISTOR >
Q630 8-729-422-57 TRANSISTOR BN1A4M-TP
Q631 8-729-422-57 TRANSISTOR BN1A4M-TP
Q632 8-729-422-57 TRANSISTOR BN1A4M-TP
Q633 8-729-422-57 TRANSISTOR BN1A4M-TP
Q634 8-729-422-57 TRANSISTOR BN1A4M-TP
Q635 8-729-422-57 TRANSISTOR BN1A4M-TP
< RESISTOR >
R685 1-249-417-11 CARBON 1K 5% 1/4W F
R686 1-249-418-11 CARBON 1.2K 5% 1/4W F
R687 1-249-420-11 CARBON 1.8K 5% 1/4W F
R688 1-249-422-11 CARBON 2.7K 5% 1/4W F
R689 1-247-843-11 CARBON 3.3K 5% 1/4W
R750 1-249-406-11 CARBON 120 5% 1/4W F
R751 1-249-406-11 CARBON 120 5% 1/4W F
R752 1-249-406-11 CARBON 120 5% 1/4W F
R753 1-249-406-11 CARBON 120 5% 1/4W F
R754 1-249-406-11 CARBON 120 5% 1/4W F
R755 1-249-406-11 CARBON 120 5% 1/4W F
< SWITCH >
S642 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP)
S643 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S644 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S645 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S646 1-762-875-21 SWITCH, KEYBOARD (CD OPEN/CLOSE)
**************************************************************
A-4428-079-A POWER AMP BOARD, COMPLETE
(AED,AEP,CIS,G,UK,US)
***************************
A-4428-094-A POWER AMP BOARD, COMPLETE
(AR,AUS,E,EA,KR,MX,MY,SP,TW)
***************************
A-4428-336-A POWER AMP BOARD, COMPLETE (CND)
***************************
A-4428-901-A POWER AMP BOARD, COMPLETE (TH)
***************************
1-533-293-31 FUSE HOLDER
< CAPACITOR >
C501 1-126-963-11 ELECT 4.7uF 20.00% 50V
C502 1-162-294-31 CERAMIC 0.001uF 10% 50V
C503 1-162-286-31 CERAMIC 220PF 10% 50V
C504 1-104-665-11 ELECT 100uF 20.00% 10V
C507 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C508 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C509 1-128-560-11 ELECT 22uF 20.00% 100V
C510 1-128-578-11 ELECT 1uF 20.00% 100V
C511 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C512 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C541 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C542 1-127-753-11 ELECT 3300uF 20% 71V
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
C542 1-126-974-11 ELECT 3300uF 20.00% 50V
(CND)
C542 1-127-752-11 ELECT 3300uF 20% 63V
(AED,AEP,CIS,G,UK,US)
C551 1-126-963-11 ELECT 4.7uF 20.00% 50V
C552 1-162-294-31 CERAMIC 0.001uF 10% 50V
C553 1-162-286-31 CERAMIC 220PF 10% 50V
C554 1-104-665-11 ELECT 100uF 20.00% 10V
C557 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C558 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C559 1-128-560-11 ELECT 22uF 20.00% 100V
C581 1-126-967-11 ELECT 47uF 20.00% 50V
C591 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C592 1-127-753-11 ELECT 3300uF 20% 71V
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW
C592 1-126-974-11 ELECT 3300uF 20.00% 50V
(CND)
C592 1-127-752-11 ELECT 3300uF 20% 63V
(AED,AEP,CIS,G,UK,US)
C942 1-126-964-11 ELECT 10uF 20.00% 50V
C943 1-126-968-11 ELECT 100uF 20.00% 50V
C980 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN502 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
PANEL CD SWITCH POWER AMP
