Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
64
< DIODE >
D501 8-719-911-19 DIODE 1SS133T-72
D502 8-719-911-19 DIODE 1SS133T-72
D541 8-719-302-38 DIODE RBV-602-01
D551 8-719-911-19 DIODE 1SS133T-72
D581 8-719-911-19 DIODE 1SS133T-72
D941 8-719-983-99 DIODE MTZJ-T-72-39D
D979 8-719-110-31 DIODE MTZJ-T-72-12B
< EARTH >
* EP502 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 8-749-016-94 IC STK402-090 (CND)
IC501 8-749-016-96 IC STK402-120 (EXCEPT CND)
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q503 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q504 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q505 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
Q506 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
Q551 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q941 8-729-048-52 TRANSISTOR 2SA1932(TP)
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-414-11 CARBON 560 5% 1/4W F
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W F
R506 1-249-431-11 CARBON 15K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
0 R508 1-217-156-00 METAL 0.22 20% 5W
R509 1-260-076-11 CARBON 10 5% 1/2W
0 R510 1-217-156-00 METAL 0.22 20% 5W
0 R511 1-212-881-11 FUSIBLE 100 5% 1/4W
0 R512 1-202-972-61 FUSIBLE 1 5% 1/4W
R513 1-249-435-11 CARBON 33K 5% 1/4W
R514 1-249-421-11 CARBON 2.2K 5% 1/4W F
R515 1-249-433-11 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-421-11 CARBON 2.2K 5% 1/4W F
R518 1-249-435-11 CARBON 33K 5% 1/4W
R519 1-249-439-11 CARBON 68K 5% 1/4W
R521 1-249-441-11 CARBON 100K 5% 1/4W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R522 1-249-441-11 CARBON 100K 5% 1/4W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R523 1-249-441-11 CARBON 100K 5% 1/4W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R541 1-249-437-11 CARBON 47K 5% 1/4W
R551 1-249-417-11 CARBON 1K 5% 1/4W F
R552 1-249-438-11 CARBON 56K 5% 1/4W
R553 1-249-414-11 CARBON 560 5% 1/4W F
R554 1-249-438-11 CARBON 56K 5% 1/4W
R555 1-249-417-11 CARBON 1K 5% 1/4W F
R556 1-249-431-11 CARBON 15K 5% 1/4W
R557 1-249-441-11 CARBON 100K 5% 1/4W
0 R558 1-217-156-00 METAL 0.22 20% 5W
R559 1-260-076-11 CARBON 10 5% 1/2W
0 R560 1-217-156-00 METAL 0.22 20% 5W
0 R561 1-212-881-11 FUSIBLE 100 5% 1/4W
R581 1-249-435-11 CARBON 33K 5% 1/4W
R582 1-249-435-11 CARBON 33K 5% 1/4W
R591 1-249-437-11 CARBON 47K 5% 1/4W
R942 1-249-429-11 CARBON 10K 5% 1/4W
R943 1-249-417-11 CARBON 1K 5% 1/4W F
R980 1-249-429-11 CARBON 10K 5% 1/4W
< THERMISTOR >
TH501 1-807-796-11 THERMISTOR
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
**************************************************************
A-4428-082-A SUB TRANS BOARD, COMPLETE
(AED,AEP,CIS,G,UK)
**************************
A-4428-959-A SUB TRANS BOARD, COMPLETE (CND)
**************************
A-4428-088-A SUB TRANS BOARD, COMPLETE (US)
**************************
< CAPACITOR >
0 C971 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
(US)
C973 1-126-933-11 ELECT 100uF 20.00% 16V
C975 1-126-768-11 ELECT 2200uF 20.00% 16V
C976 1-164-159-11 CERAMIC 0.1uF 50V
C977 1-164-159-11 CERAMIC 0.1uF 50V
C978 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN974 1-564-321-00 PIN, CONNECTOR 2P
CN976 1-506-468-11 PIN, CONNECTOR 3P
< DIODE >
0 D971 8-719-911-19 DIODE 1SS133T-72
D972 8-719-024-99 DIODE 11ES2-NTA2B
D973 8-719-024-99 DIODE 11ES2-NTA2B
D974 8-719-024-99 DIODE 11ES2-NTA2B
D975 8-719-024-99 DIODE 11ES2-NTA2B
D976 8-719-911-19 DIODE 1SS133T-72
< IC >
IC971 8-759-039-69 IC uPC7805AHF
< TRANSISTOR >
Q971 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
SUB-TRANS
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
POWER AMP
To Next Page
