Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
65
< RESISTOR >
R974 1-249-441-11 CARBON 100K 5% 1/4W
R975 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0 RY971 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0 T972 1-435-209-11 TRANSFORMER, POWER (CND,US)
0 T972 1-435-210-11 TRANSFORMER, POWER (AED,AEP,CIS,G,UK)
**************************************************************
1-676-192-11 TRANS BOARD
************
1-533-293-31 FUSE HOLDER
< CAPACITOR >
C941 1-126-969-11 ELECT 220uF 20.00% 50V
< CONNECTOR >
CN975 1-564-321-00 PIN, CONNECTOR 2P
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
* CN977 1-564-527-11 PLUG, CONNECTOR 12P
< DIODE >
D977 8-719-024-99 DIODE 11ES2-NTA2B
< FUSE >
0 F971 1-532-506-31 FUSE 6.3A (AR,E,EA,MX,MY,SP,TW)
0 F973 1-576-109-11 FUSE 5A (US,CIS)
0 F974 1-532-506-31 FUSE 6.3A (EXCEPT CIS)
0 F974 1-576-109-11 FUSE 5A (CIS)
0 F974 1-576-193-21 FUSE 6.3A (US)
0 F975 1-532-506-31 FUSE 6.3A (EXCEPT CIS)
0 F975 1-576-109-11 FUSE 5A (CIS)
0 F975 1-576-193-21 FUSE 6.3A (US)
< RESISTOR >
0 R941 1-202-972-61 FUSIBLE 1 5% 1/4W
0 R951 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0 R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0 R953 1-219-120-11 FUSIBLE 0.15 5% 1/4W
R961 1-202-725-00 SOLID 3.3M 10% 1/2W
(US)
< TRANSFORMER >
0 T972 1-435-261-11 TRANSFORMER, POWER (AED,AEP,CIS,UK)
0 T972 1-435-262-11 TRANSFORMER, POWER
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
0 T972 1-435-263-11 TRANSFORMER, POWER (CND)
0 T972 1-435-264-11 TRANSFORMER, POWER (US)
< SWITCH >
0 S951 1-771-291-31 SWITCH, POWER (VOL SEL)
(AR,E,EA,MY,SP,TW)
**************************************************************
MISCELLANEOUS
**************
M961 1-763-072-11 FAN, D.C. (AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
101 1-773-045-11 WIRE (FLAT TYPE) (17 CORE)
104 1-773-122-11 WIRE (FLAT TYPE) (19 CORE)
0 108 1-696-847-11 CORD, POWER (AUS)
0 108 1-769-079-21 CORD, POWER (KR)
0 108 1-777-071-51 CORD, POWER (AED,AEP,CIS,EA,MY,SP,TW)
0 108 1-783-820-11 CORD, POWER (CND,US)
0 108 1-783-941-11 CORD, POWER (AR)
0 108 1-790-226-11 CORD, POWER (UK,G)
0 108 1-791-901-11 CORD, POWER (E,MX,TH)
0 109 1-569-008-31 ADAPTOR, CONVERSION (EA,MY,SP,TW)
209 1-791-983-12 WIRE (FLAT TYPE) (8 CORE)
216 1-471-035-11 MAGNET ASSY
0 222 A-4735-357-A BASE ASSY, OP (KSM-213D)
225 1-792-024-11 WIRE (FLAT TYPE)(16 CORE)
**************************************************************
**************
HARDWARE LIST
**************
#1 7-628-254-05 SCREW +PS 2.6X5
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
#5 7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S
#6 7-685-881-09 SCREW +BVTT 4X8 (S)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
SUB-TRANS TRANS
Ver 1.3 2003.11
To Next Page
