Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
48
HCD-CP101
R880 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R881 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R882 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R883 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R884 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R885 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R886 1-216-821-11 METAL CHIP 1K 5% 1/10W
R887 1-216-821-11 METAL CHIP 1K 5% 1/10W
R888 1-216-821-11 METAL CHIP 1K 5% 1/10W
R890 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R891 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R892 1-216-817-11 METAL CHIP 470 5% 1/10W
R894 1-216-821-11 METAL CHIP 1K 5% 1/10W
R895 1-216-821-11 METAL CHIP 1K 5% 1/10W
R896 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R897 1-216-821-11 METAL CHIP 1K 5% 1/10W
R898 1-216-821-11 METAL CHIP 1K 5% 1/10W
R899 1-216-821-11 METAL CHIP 1K 5% 1/10W
< TERMINAL BOARD/JACK >
SJ301 1-694-820-11 TERMINAL BOARD
(SPEAKER IMPEDANCE USE 6-16Ω)
SJ302 1-815-045-11 JACK, PIN 2P (AUDIO IN MD (VIDEO))
< THERMISTOR >
TH1 1-537-770-21 TERMINAL BOARD, GROUND
TH2 1-537-770-21 TERMINAL BOARD, GROUND
< TUNER PACK >
TU1 A-4303-953-A TUNER PACK (AEP, UK, KR, AUS)
TU1 A-4303-954-A TUNER PACK (US, CND, E, SP, MX, AR)
< VIBRATOR >
X801 1-579-901-11 VIBRATOR, CERAMIC (4.19MHz)
X802 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X803 1-579-242-41 VIBRATOR, CRYSTAL (4.332MHz) (AEP, UK)
**************************************************************
1-681-807-11 MOTOR BOARD
**************
* 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-771-799-11 SWITCH, LEVER SLIDE
(CD LID OPEN/COLSE DETECT)
**************************************************************
A-4728-261-A POWER BOARD, COMPLETE (AEP, UK, AUS)
A-4729-303-A POWER BOARD, COMPLETE (E, SP, AR)
A-4729-396-A POWER BOARD, COMPLETE (US, CND)
A-4729-399-A POWER BOARD, COMPLETE (MX)
A-4730-026-A POWER BOARD, COMPLETE (KR)
***********************
1-533-313-11 HOLDER, FUSE
< CAPACITOR >
0 C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
C910 1-161-494-00 CERAMIC 0.022uF 25V
C911 1-126-947-11 ELECT 47uF 20% 16V
C917 1-126-934-11 ELECT 220uF 20% 10V
C918 1-126-964-11 ELECT 10uF 20% 50V
C919 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C920 1-104-666-11 ELECT 220uF 20% 25V
C921 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C922 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P
* CN902 1-766-281-11 PIN, CONNECTOR (PC BOARD) 8P
< DIODE >
D902 8-719-902-17 DIODE 1N5401
D903 8-719-902-17 DIODE 1N5401
D904 8-719-902-17 DIODE 1N5401
D905 8-719-902-17 DIODE 1N5401
D906 8-719-046-07 DIODE 2A02M
D907 8-719-046-07 DIODE 2A02M
D908 8-719-046-07 DIODE 2A02M
D909 8-719-046-07 DIODE 2A02M
D910 8-719-991-33 DIODE 1SS133T-77
D911 8-719-991-33 DIODE 1SS133T-77
D912 8-719-991-33 DIODE 1SS133T-77
D913 8-719-991-33 DIODE 1SS133T-77
D915 8-719-109-97 DIODE MTZJ-T-77-6.8B
D917 8-719-991-33 DIODE 1SS133T-77
D918 8-719-109-93 DIODE MTZJ-T-77-6.2B
< LINE FILTER >
0 LF901 1-424-150-11 TRANSFORMER, LINE FILTER (US, CND)
< TRANSISTOR >
Q901 8-729-028-54 TRANSISTOR KTC3205-Y-AT
Q902 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q903 8-729-028-54 TRANSISTOR KTC3205-Y-AT
< RESISTOR >
R902 1-249-425-11 CARBON 4.7K 5% 1/4W
R903 1-249-409-11 CARBON 220 5% 1/4W
R904 1-249-425-11 CARBON 4.7K 5% 1/4W
R905 1-249-437-11 CARBON 47K 5% 1/4W
0 R909 1-219-237-11 SOLID 3.3M 20% 1/2W
(US, CND)
< RELAY >
0 RY901 1-755-332-11 RELAY
MAIN MOTOR POWER
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
