Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
49
HCD-CP101
< SWITCH >
0 S901 1-786-152-11 SWITCH, SLIDE (VOLTAGE SELECTOR)
(E, SP, AR)
< TRANSFORMER >
0 T901 1-437-844-11 TRANSFORMER, POWER (E, SP, AR)
0 T901 1-437-730-11 TRANSFORMER, POWER (AEP, UK, KR, AUS)
0 T901 1-437-731-11 TRANSFORMER, POWER (US, CND, MX)
**************************************************************
A-4728-263-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C102 1-126-933-11 ELECT 100uF 20% 16V
C104 1-130-483-00 MYLAR 0.01uF 5% 50V
C105 1-126-960-11 ELECT 1uF 20% 50V
C106 1-126-964-11 ELECT 10uF 20% 50V
C107 1-126-960-11 ELECT 1uF 20% 50V
C108 1-126-961-11 ELECT 2.2uF 20% 50V
C109 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C110 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C111 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C201 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C202 1-126-933-11 ELECT 100uF 20% 16V
C204 1-130-483-00 MYLAR 0.01uF 5% 50V
C205 1-126-960-11 ELECT 1uF 20% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-960-11 ELECT 1uF 20% 50V
C208 1-126-961-11 ELECT 2.2uF 20% 50V
C209 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C210 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C211 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C400 1-126-964-11 ELECT 10uF 20% 50V
C401 1-126-933-11 ELECT 100uF 20% 16V
C402 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C403 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C407 1-126-965-11 ELECT 22uF 20% 50V
C410 1-126-960-11 ELECT 1uF 20% 50V
C422 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C432 1-136-967-11 MYLAR 0.012uF 5% 50V
C433 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C434 1-126-947-11 ELECT 47uF 20% 35V
C435 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C436 1-126-933-11 ELECT 100uF 20% 16V
C437 1-126-965-11 ELECT 22uF 20% 50V
< CONNECTOR >
CN301 1-784-778-11 CONNECTOR, FFC 17P
CN302 1-691-040-31 CONNECTOR, FFC 8P
< DIODE >
D401 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC401 6-702-130-01 IC HA12237F
< RESISTOR >
JR102 1-216-864-11 METAL CHIP 0 5% 1/10W
JR103 1-216-864-11 METAL CHIP 0 5% 1/10W
JR104 1-216-864-11 METAL CHIP 0 5% 1/10W
JR105 1-216-864-11 METAL CHIP 0 5% 1/10W
JR106 1-216-864-11 METAL CHIP 0 5% 1/10W
JR201 1-216-864-11 METAL CHIP 0 5% 1/10W
< TRANSISTOR >
Q100 8-729-212-02 TRANSISTOR 2SC2120-T
Q101 8-729-212-02 TRANSISTOR 2SC2120-T
Q200 8-729-212-02 TRANSISTOR 2SC2120-T
Q201 8-729-212-02 TRANSISTOR 2SC2120-T
Q401 8-729-212-02 TRANSISTOR 2SC2120-T
Q402 8-729-037-02 TRANSISTOR KTA1266Y-AT
Q403 8-729-038-67 TRANSISTOR KRC102S
Q404 8-759-068-54 TRANSISTOR KRA102S
Q405 8-729-038-71 TRANSISTOR KRC107S
< RESISTOR >
R101 1-216-841-11 METAL CHIP 47K 5% 1/10W
R102 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R103 1-216-833-11 METAL CHIP 10K 5% 1/10W
R104 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R105 1-216-841-11 METAL CHIP 47K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-833-11 METAL CHIP 10K 5% 1/10W
R109 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R111 1-216-833-11 METAL CHIP 10K 5% 1/10W
R112 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R113 1-216-797-11 METAL CHIP 10 5% 1/10W
R201 1-216-841-11 METAL CHIP 47K 5% 1/10W
R202 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R203 1-216-833-11 METAL CHIP 10K 5% 1/10W
R204 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R205 1-216-841-11 METAL CHIP 47K 5% 1/10W
R206 1-216-833-11 METAL CHIP 10K 5% 1/10W
R207 1-216-833-11 METAL CHIP 10K 5% 1/10W
R208 1-216-833-11 METAL CHIP 10K 5% 1/10W
R209 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R211 1-216-833-11 METAL CHIP 10K 5% 1/10W
R212 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R213 1-216-797-11 METAL CHIP 10 5% 1/10W
R400 1-218-446-11 METAL CHIP 1 5% 1/10W
R401 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R402 1-216-803-11 METAL CHIP 33 5% 1/10W
R403 1-216-805-11 METAL CHIP 47 5% 1/10W
R404 1-216-833-11 METAL CHIP 10K 5% 1/10W
R405 1-216-797-11 METAL CHIP 10 5% 1/10W
R406 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R407 1-216-841-11 METAL CHIP 47K 5% 1/10W
R408 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R409 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
POWER TC
Ver 1.2
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
